Jerónimo Agulló is an open-source projects enthusiast and a Zephyr RTOS contributor. He has worked on different IoT projects across different industries, from research centers such as the University of Sevilla, to large companies like Ferrovial Construction. Check out his work on his GitHub profile.

Location is a basic part of the most interesting IoT systems. It’s not just about loss prevention; geolocation opens the door to several applications and enhances the management of devices. In many cases, this involves Global Navigation Satellite System (GNSS).

Position is so important in IoT that the latest Zephyr release (v3.6.0) has added a new API for GNSS based on the NMEA0183 standard. Today I’m going to explain the basics of GNSS, what NMEA means, and dive into this awesome new Zephyr feature.

The basics of the NMEA standard

NMEA is the acronym for the National Marine Electronics Association, an organization created before GPS was invented. Its aim is creating better communications with manufacturers. I can assure you that they achieved their goal with GNSS.

Their most extended and well-known norm is the NMEA0183 protocol, which has become the GNSS standard for almost all manufacturers. It facilitates module integration and new applications development.

NMEA data is transmitted from a source such as a GPS module (known as a “Talker”) to equipment, such as our running Zephyr device (known as a “Listener”). One important aspect is that a single talker can communicate to many listeners.

From the electronic perspective, NMEA0183 originally used RS-422, but now uses several interfaces such as UART, USB, RS-232, WIFI, Bluetooth, and more. We can consider NMEA protocol as a common message structure standard. NMEA0183 protocol makes software developer life easier due to the standardization between GNSS devices.

NMEA message structure

Each NMEA sentence contains only ASCII characters, starting with the dollar symbol “$” and ending with the <CR> (Carriage return) and <LF> (Line feed) characters. The content of the message is a tuple, separated by commas. This starts with an NMEA identifier, followed by data, and ending by a checksum preceded by an asterisk “*”.

For a better understanding, let’s examine a popular NMEA sentence from a Quectel module. “GGA” sentence contains the Global Positioning System fix data, time, position, and fix related data for a GNSS receiver.

$GPGGA,102744.00,6155.393269,N,00848.433734,E,1,03,1.6,821.5,M,52.0,M,,*70
  • $GPGGA is the sentence identifier which can be split into “GP” which means the GNNS type, in this case GPS, and “GGA” which is the sentence identifier.
  • 102744.00 is the time of fix (hhmmss).
  • 6155.393269,N is the latitude (ddmm.mmm format, N for North).
  • 00848.433734,E is the longitude (dddmm.mmm format, E for East).
  • 1 is the fix quality indicator.
  • 03 is the number of satellites being tracked.
  • 1.6 is the horizontal dilution of precision.
  • 821.5,M is the altitude in meters above mean sea level.
  • 52.0,M is the height in meters of geoid separation.
  • *70 is the checksum (Note: this is not the correct checksum for this payload, we moved the location manually)



All talker devices don’t rely on GPS or on different constellations simultaneously. The most common constellations are GLONASS (GL), BEIDOU(DB or GB) and GALILEO (GA).

Besides GGA, other popular NMEA sentences are:

  • RMC: Recommended Minimum Navigation Information
    • This contains information similar to GGA such as the latitude and longitude and also the speed over ground (in knots), the date and the magnetic variation (in degrees).
  • GSV: Satellites in View
    • This NMEA message prints information such as the total number of satellites in view for each constellation and for each satellite its number (PRN), elevation in degrees, azimuth in degrees and Signal to Noise Ratio (SNR) in dB. Each GSV sentence contains the information of more than one satellite.

The previous NMEA sentences are named as “talker sentences”. In addition to that, there are “Proprietary sentences” and “query sentences”. On the one hand, the proprietary sentences start with “$P” and allow manufacturers to define custom NMEA sentences format for custom functions such as power management. On the other hand, the query sentences are the means for listener to request a particular sentence from a talker

Zephyr GNSS API

If you’ve reached this point, it means that you already know and like Zephyr RTOS. If you’re not familiar with Zephyr, I encourage you to familiarize yourself with it by using this getting started guide.

Zephyr RTOS is not just a simple scheduler for simple applications. Zephyr is a whole operating system with drivers, services and common APIs which facilitates the new developments and sensors and boards exchange. I would go beyond and say that Zephyr is even a complete ecosystem with integration in awesome clouds such as Golioth.

A great example of this affirmation is the new Zephyr GNSS support in version v3.6.0. The GNSS API is built upon the modem subsystem, which provides the necessary modules to communicate with modems. The GNSS subsystem covers everything from sending and receiving commands to and from the modem, to parsing, creating and processing NMEA0183 messages.

The source code can be found under the path zephyr/drivers/gnss, which is divided into specific GNSS module drivers with custom features such as power management, some files with utils and a generic NMEA0183 driver. Covering in detail each of those utils would require a whole new post. However, I will provide a brief overview of each of them:

  • gnss_dump
    • A set of utilities to get, convert and print GNSS information into readable and useful data.
  • gnss_nmea0183 and gnss_parse
    • NMEA0183 utilities such as checksum calculation, parsing a ddmm.mmmm formatted coordinates to nano degrees or parsing the content of GGA, RMC and GSV NMEA messages.
  • gnss_nmea0183_match
    • This code is based on “modem_chat” match handlers, a Zephyr utility to process messages from modems. The callbacks to parse GGA, RMC and GSV messages are defined here.

Zephyr has created a generic NMEA driver which can be used for any NMEA talker. As any other driver, it is instantiated by the DEVICE_DT_INST_DEFINE macro. It includes the following code to call the callbacks defined in the gnss_nmea0183_match.c for corresponding NMEA identifier:

MODEM_CHAT_MATCHES_DEFINE(unsol_matches,
MODEM_CHAT_MATCH_WILDCARD("$??GGA,", ",*", gnss_nmea0183_match_gga_callback),
MODEM_CHAT_MATCH_WILDCARD("$??RMC,", ",*", gnss_nmea0183_match_rmc_callback),
#if CONFIG_GNSS_SATELLITES
MODEM_CHAT_MATCH_WILDCARD("$??GSV,", ",*", gnss_nmea0183_match_gsv_callback),
#endif
);

GNSS example in Zephyr

Now you know about NMEA0183 and the Zephyr GNSS API, so get your hands dirty and write some code! The full code can be found in my github repository:

https://github.com/jeronimoagullo/Zephyr-GNSS-Sample

KConfig Changes

In this example, I will show you how to configure a microcontroller in Zephyr to use a GNSS module which supports NMEA0183. For this aim, I will use an ESP32S3-Mini-1 development board along with an Air530z GNSS module. We’re going to modify our prj.conf file

  1. Add the CONFIG_GNSS=y kconfig variable to add the GNSS support.
  2. Add the variables CONFIG_GNSS_SATELLITES=y to display satellites’ information
  3. Add CONFIG_GNSS_DUMP_TO_LOG=y to print GNSS information like the fixation status, coordinates and time.

Devicetree Changes

Next, we’ll configure the device tree correctly for our GNSS module. In this case, the Air530z GNSS module uses an UART interface. By default, ESP32S3 has the UART0 configured in pins 43 and 44. However, this UART is configured at 115200 bps and used for both programming the board and by Zephyr to print messages into the serial terminal. This is not a good idea.

What is the solution? The use of another UART, for example, the UART1. However, it is not defined in esp32s3_devkitm.dts. So let ‘s do it!

According to GPIO, the UART1 uses the pins 17 and 18 (you can use others too). I have chosen these default pins and defined them in the device tree overlay using the pin control subsystem. The macro of the pins can be found in the file zephyr/include/zephyr/dt-bidings/pinctrl/esp32s3-pinctrl.h you can find your board pins in the corresponding header file of your board.



&pinctrl {

  uart1_pins: uart1_pins {
    group1 {
      pinmux = <UART1_TX_GPIO17>;
      output-high;
    };

    group2 {
      pinmux = <UART1_RX_GPIO18>;
        bias-pull-up;
      };
    };

};

Then, in the UART node, I have added our above pin definition and a “gnss-nmea-generic” compatible device. I have created an alias to this GNSS device to facilitate the access from the main code.

&uart1 {

  status = "okay";
  current-speed = <9600>;
  pinctrl-0 = <&uart1_pins>;
  pinctrl-names = "default";
  gnssdev: gnss-nmea-generic {
    compatible = "gnss-nmea-generic";
  };

};

Finally, the main code uses the GNSS_DATA_CALLBACK_DEFINE macro to define a callback for getting the information about satellites in view and another for GNSS information such as time, coordinates and tracking satellites. The following screenshot depicts the application output:



We managed to get the GNSS data!

Final thoughts

We have covered in this post what NMEA means and its importance in GNSS as well as the main NMEA messages, how the new Zephyr GNSS API relies on NMEA, and a sample of how to localize our device using Zephyr. Now, it is your turn to send the GNSS data to Golioth cloud!

In this post, we’ll walk through a couple methods for defining abstract hardware interfaces in Zephyr using the devicetree.

You’ve probably seen abstract hardware interfaces implemented on popular development boards. Many boards provide a standardized connector interface like mikroBUS, Feather, MicroMod, Arduino UNO, etc. A defining characteristic of these interfaces is the ability to plug in a range of peripheral boards that do different things, but still all use the same signals.

For example, a MikroE Weather Click board that implements the mikroBUS standard can be plugged into a LPCXpresso55S28 dev board or a STM32 M4 Clicker dev board without requiring any hardware changes to the Weather Click boards. The signals are always in the same place on the ClickBus form factor (even if each Click board doesn’t use all of them).

Using abstract interfaces can enable writing more portable devicetree definitions that can be reused across multiple boards.

Same app, multiple boards

We’ve been updating our collection of Golioth reference designs to support our Follow-Along Hardware boards. These are designs you can build yourself using off-the-shelf development boards.

Zephyr’s Devicetree support enables us to decouple the hardware definition for each board from the application source code. By using devicetree interfaces to the underlying hardware, we can target completely different boards (or different revisions of the same board) without any changes to the application code.

For example, the images below show two supported boards that run the same Air Quality Monitor reference design firmware:

Golioth Aludel Mini board

nRF9160 DK FAH board

Why use abstract hardware interfaces?

Look closely at the images above. You’ll notice that both platforms are hosting the exact same MikroE Click sensor modules.

These Click modules adhere to the mikroBUS socket specification, ensuring that any Click board can be plugged into any standard mikroBUS socket:

The Golioth Aludel Mini board in the left photo above includes two built-in MikroBUS sockets. The nRF9160 DK board in the right photo above uses an Arduino UNO Click shield to convert the onboard Arduino socket into two MikroBUS sockets.

The Weather Click board we’re using in the Air Quality Monitor reference design uses the I2C interface on the mikroBUS socket to read weather data from the onboard BME280 sensor.

On our custom Golioth Aludel Mini board, the mikroBUS I2C interface is connected to the nRF9160’s I2C1 peripheral. We could describe this hardware in the application’s aludel_mini_v1_sparkfun9160_ns.overlay file like this:

&i2c1 {
	status = "okay";

	bme280: bme280@76 {
		compatible = "bosch,bme280";
		reg = <0x76>;
	};
};

However, on the off-the-shelf nRF9160 DK Follow-Along Hardware board, the mikroBUS I2C interface is connected to the nRF9160’s I2C2 peripheral (through the Arduino UNO Click shield). Similarly, we could describe this hardware in the application’s nrf9160dk_nrf9160_ns.overlay file like this:

&i2c2 {
	status = "okay";

	bme280: bme280@76 {
		compatible = "bosch,bme280";
		reg = <0x76>;
	};
};

There are a couple downsides to this approach:

  1. It’s not very DRY. We are repeating the same bme280 node definition in each board overlay file in the application. If we swapped out the Weather Click board for a board with a different sensor, we’d have to update each board definition individually.
  2. It doesn’t reflect the actual hardware interface. The definitions above tightly couple the sensor hardware definitions to specific MCU peripherals on each board. As a result, we need a slightly different sensor configuration for each board.

Node labels as abstract interfaces

One simple way to address the downsides listed above is to define an abstract hardware interface using node labels.

Defining abstract hardware interfaces in boards

We can add node labels in a board’s devicetree definition for the mikroBUS UART, I2C, and SPI communication interfaces. Here’s the mikroBUS node labels for the Golioth Aludel Mini board from the aludel_mini_v1_sparkfun9160_common.dtsi file:

mikrobus_serial: &uart2 {};
mikrobus_i2c: &i2c1 {};
mikrobus_spi: &spi2 {};

Because the mikroBUS abstract interface is implemented directly by this board, these node labels map directly to specific peripherals on the nRF9160 MCU.

On the other hand, the nRF9160 DK doesn’t have any built-in mikroBUS sockets, so the nrf9160dk/nrf9160 board definition does not include these mikrobus_* node labels. However, if we enable the Arduino UNO Click shield (-DSHIELD="arduino_uno_click") when building for the nrf9160dk/nrf9160 board, the built-in arduino_uno_click.overlay will include the following mikrobus_* node labels:

mikrobus_spi: &arduino_spi {};
mikrobus_serial: &arduino_serial {};
mikrobus_i2c: &arduino_i2c {};

Since the mikroBUS abstract interface is implemented by the Arduino UNO Click shield, these node labels simply “pass through” to the arduino_* abstract interface implemented in the nrf9160dk_nrf9160_common.dtsi file.

(Currently, there is a bug with the mikrobus_i2c interface when using the arduino_uno_click shield with the nrf9160dk/nrf9160 board. See this PR for a fix.)

Using abstract hardware interfaces in overlays

Since all the boards supported by our application implement the mikrobus_* abstract interface, we can define the devicetree nodes for the Click boards in a single place using these node labels. For example, we could create a single application-level overlay app.overlay for the Weather Click board:

&mikrobus_i2c {
	status = "okay";

	bme280: bme280@76 {
		compatible = "bosch,bme280";
		reg = <0x76>;
	};
};

Using abstract hardware interfaces in Shields

We can even take this one step further and turn this app.overlay into a mikroe_weather_click Zephyr Shield that we can use across multiple apps.

First, we need to add a boards/shields/mikroe_weather_click/Kconfig.shield with the following config:

config SHIELD_MIKROE_WEATHER_CLICK
	def_bool $(shields_list_contains,mikroe_weather_click)

Next, we add a boards/shields/mikroe_weather_click/mikroe_weather_click.overlay with the same devicetree code from the app.overlay above:

&mikrobus_i2c {
	status = "okay";

	bme280_mikroe_weather_click: bme280@76 {
		compatible = "bosch,bme280";
		reg = <0x76>;
	};
};

Now we can simply include this shield overlay in any app by specifying the argument -DSHIELD="mikroe_weather_click" in the build command.

For example, to build the samples/sensor/bme280 app for the nRF9160 DK board + Arduino UNO Click shield + Weather Click shield:

west build -p -b nrf9160dk/nrf9160/ns samples/sensor/bme280 -- -DSHIELD="arduino_uno_click mikroe_weather_click"

(This PR adds the mikroe_weather_click shield to upstream Zephyr.)

GPIO Nexus Nodes

The mikroBUS interface described earlier defines a set of GPIO used for various purposes by the Click modules: SPI chip select (CS), enable (EN), reset (RST), interrupt (INT), etc. This is essentially an abstract interface for a group of GPIO pins. Any board that implements mikroBUS must map these pins on the socket to SoC-specific GPIO on the board.

So far, we’ve described how to define and use abstract interfaces via node labels. However, there is no single node in the devicetree that represents a GPIO pin. You can’t use a single phandle to represent one.

Instead, the Devicetree specification provides Nexus Nodes for creating these types of mappings. Specifically, GPIO nexus nodes provide a mapping between an abstract GPIO interface and the actual GPIO pins on a SoC.

For example, we can take a look at the mikroBUS GPIO nexus node defined for the lpcxpresso55s36 board:

mikrobus_header: mikrobus-connector {
	compatible = "mikro-bus";
	#gpio-cells = <2>;
	gpio-map-mask = <0xffffffff 0xffffffc0>;
	gpio-map-pass-thru = <0 0x3f>;
	gpio-map =	<0 0 &gpio1 9 0>,	/* AN  */
			/* Not a GPIO*/		/* RST */
			<2 0 &gpio0 20 0>,	/* CS   */
			<3 0 &gpio1 2 0>,	/* SCK  */
			<4 0 &gpio1 3 0>,	/* MISO */
			<5 0 &gpio0 26 0>,	/* MOSI */
						/* +3.3V */
						/* GND */
			<6 0 &gpio1 8 0>,	/* PWM  */
			<7 0 &gpio0 17 0>,	/* INT  */
			<8 0 &gpio1 24 0>,	/* RX   */
			<9 0 &gpio1 25 0>,	/* TX   */
			<10 0 &gpio1 30 0>,	/* SCL  */
			<11 0 &gpio1 21 0>;	/* SDA  */
						/* +5V */
						/* GND */
};

The main thing to highlight here is that the gpio-map is a mapping, where each row maps an abstract GPIO “specifier” (e.g. <&mikrobus_header 2 0>) to a real GPIO “specifier” on the LPC55S36 MCU (e.g. <&gpio0 20 0>). See the Zephyr documentation for GPIO nexus nodes and the devicetree spec for detailed descriptions of the other properties.

We can now refer to <&mikrobus_header 2 0> instead of <&gpio0 20 0> when referring to GPIOs in devices that use the mikroBUS interface. This is good because it means that we can define an app.overlay or a <shield>.overlay that is not tied to a specific SoC pin on a board.

Devicetree Aliases & Chosen Nodes

The methods we’ve shown above are helpful for defining abstract interfaces between hardware devices within devicetree. In this final section, we’ll show how to expose abstract hardware interfaces to your application via aliases & chosen nodes.

These provide a way to refer to abstract nodes without having any knowledge of the specific hardware implementation. In general, the idea is to use abstract node labels (mikrobus_i2c) to decouple devicetree definitions from board-specific devices, and use aliases/chosen nodes to decouple the application code from board-specific devices.

For example, it’s possible to build the zephyr/samples/basic/blinky app for many different boards without changing any of the application code. The only requirement is that each board’s devicetree definition must provide the board-specific implementation for the led0 alias—the abstract interface used by the application code:

leds {
	compatible = "gpio-leds";
	led0: led_0 {
		gpios = <&gpio0 2 0>;
	};
	...
};

aliases {
	led0 = &led0;
	...
};

You can access this led0 alias in your application code like this:

#define LED0_NODE DT_ALIAS(led0)

static const struct gpio_dt_spec led = GPIO_DT_SPEC_GET(LED0_NODE, gpios);

Conclusion

Devicetree stuff is never clear on the first reading, but is super logical in the long run. Hopefully this was helpful in clarifying how to define and use abstract hardware interfaces in devicetree. If you have any follow up questions or comments, feel free to reach out in our forum.

Interested in learning more about Zephyr? Then, we’d love to have you join us for a free Zephyr developer training. Our next session is coming up in May. Sign up now!

Golioth works with Qualcomm

We’re excited to announce the latest update to the Golioth Firmware SDK, release 0.12.0, which now includes support for Zephyr’s newly introduced Modem Subsystem. This enhancement significantly increases the flexibility of our platform, enabling support for a broader array of cellular modem technologies, starting with Qualcomm. 0.12.0 adds support for the Quectel BG95, joining the Nordic Semiconductor nRF9160 (our go-to modem around here!) as a first class cellular modem. We also introduced additional ways to securely store credentials.

Zephyr’s New Modem Subsystem

Introduced in Zephyr 3.5.0, the Modem Subsystem is a unified interface for modem drivers. This addition simplifies the integration of cellular modems (and others) into Zephyr-based projects, greatly expanding the range of devices and technologies that developers can utilize effectively. For a detailed overview of the modem subsystem, check out this summary from Zephyr’s Developer Advocate, Benjamin Cabé.

Integration in Golioth Firmware SDK

With the integration of this modem subsystem in the Golioth Firmware SDK, Golioth users can now more flexibly incorporate a wider array of modem technologies into their IoT projects. There are a lot of great modems and module vendors in the market and providing choice is at the heart of what we do at Golioth.

First Supported Modem and Board

The first modem we are supporting with this updated SDK is the BG95 from Quectel, based on Qualcomm technology. The BG95 is paired with the nRF52840 on the RAK5010 development board from RAKwireless. This combination highlights the flexibility of Qualcomm’s technology integrated into Quectel’s hardware, offering developers robust tools for deploying cellular IoT solutions efficiently.

Why Qualcomm?

We chose to support Qualcomm modems because our community asked for it! Developers have different design needs and want maximum flexibility. They need more options that accommodate diverse business needs. Qualcomm chipsets offer the latest in connectivity protocols and radio technology at competitive prices. Qualcomm provides silicon and support for a wide ecosystem of module vendors, such as Quectel, U-Blox, Telit, and more. Golioth customers have used Qualcomm modems in their products in the past, but needed to do much of the integration engineering themselves. Zephyr’s Modem Subsystem makes it easier to develop applications that integrate Qualcomm modems. Connecting this wider range of modems to Golioth is more hands-off for the user, reducing complexity. Developers can focus more on innovation and less on technical hurdles.

Also in This Release

In addition to new modem support, this release introduces a another feature: DTLS socket offloading for Zephyr. This includes an example for the long-supported Nordic Semiconductor nRF9160.

DTLS socket offloading leverages a modem’s secure credential store, which allows for the use of secure, offloaded sockets. This means there is not any private key material in RAM. This can be a significant advantage as it helps reduce RAM usage, code size, CPU load, and power consumption. Actual benefits will vary depending on the application and how the code is utilized.

This new feature enhances device security and efficiency, contributing further to the versatility and robustness of the Golioth Firmware SDK. Mike previously wrote how to store credentials on the nRF9160 using TLS tags.

Getting Started

To get started with the latest SDK:

  1. Update to the newest release, 0.12.0, from the Golioth Firmware SDK repository.
  2. Explore the documentation and examples provided for integrating the RAK5010 board or try DTLS socket offloading with the nRF9160.
  3. Visit our community forums or support channels if you need help or want to discuss your projects.

Focused on Your Success

At Golioth, we’re committed to providing you with the tools and flexibility needed to succeed in the fast-evolving world of IoT. By adding support for new modems and enhancing the ways you can manage credentials, we aim to streamline your development process and empower your innovative projects. Whether you’re integrating the latest modem technology or implementing secure credential management, Golioth is here to support every step of your journey towards building smarter, more connected solutions.

In a previous post on Debugging nRF9160 Zephyr apps with Ozone, I showed how to use the New Project Wizard to create a new Ozone project for debugging a Zephyr app.

However, the project files generated by the New Project Wizard contain hard-coded paths. This makes them unsuitable for sharing with colleagues or checking them into a git repository.

In this post, I’ll demonstrate how to create a portable Ozone project file that you can check into your Zephyr application’s git repository.

Build the example app

To make this example concrete, we’ll be debugging the zephyr/samples/basic/blinky/ app from the nRF Connect SDK Zephyr repo. The firmware image will be built for the nrf9160dk_nrf9160_ns target running on the Nordic nRF9160 DK board. However, the concepts in the examples below should apply to any Zephyr app or board.

I’ve manually added an additional debug KConfig fragment file that we’ll be merging in to this app during the build process. This debug.conf file enables thread-aware debugging in Ozone:

CONFIG_DEBUG_THREAD_INFO=y

# CONFIG_DEBUG_THREAD_INFO needs the heap memory pool to
# be defined for this app
CONFIG_HEAP_MEM_POOL_SIZE=256

To build the firmware for the example blinky app:

cd <your ncs workspace>/
west build -p -b nrf9160dk_nrf9160_ns zephyr/samples/basic/blinky/ -- -DEXTRA_CONF_FILE="debug.conf"

If the build completed successfully, you’ll see the build/zephyr/zephyr.elf & build/zephyr/merged.hex files we need to start a debugging session in Ozone.

Create a portable Ozone project file

Next, we’ll create a portable Ozone project file.

I’ll show the entire file first so you can see what it looks like all put together, and then I’ll walk through what each line in the file does in more detail.

I named my project file nRF9160.jdebug and located it in the root of my NCS workspace, but you can name this file anything you want (the file extension should be .jdebug):

void OnProjectLoad(void)
{
	Project.SetDevice("nRF9160_xxAA");
	Project.SetTargetIF("SWD");
	Project.SetTIFSpeed("4 MHz");
	Project.AddSvdFile("$(InstallDir)/Config/CPU/Cortex-M33F.svd");
	File.Open("$(ProjectDir)/build/zephyr/zephyr.elf");
	Project.SetOSPlugin("ZephyrPlugin.js");
}

void TargetDownload(void)
{
	Exec.Download("$(ProjectDir)/build/zephyr/merged.hex");
}

Ozone scripts

Project files in Ozone are scripts written in a simplified C-style language. Ozone defines a set of event handler functions that are called when specific debug events happen in the debugger.

The OnProjectLoad() event handler is executed when the project file is opened, so this is where we’ll do most of the setup for our project.

Project action functions

The nRF9160 DK board has an onboard SEGGER J-Link OB debugger which is connected to the nRF9160 SIP via SWD.

Ozone defines a set of project actions that can be used to configure the debugger settings:

  • Project.SetDevice("nRF9160_xxAA"); configures the debugger for the nRF9160 SIP
  • Project.SetTargetIF("SWD"); configures the debugger to use the Serial Wire Debug (SWD) protocol
  • Project.SetTIFSpeed("4 MHz"); sets the SWD signaling speed to 4 MHz

Next, we need to provide the debugger with a link to the System View Description (SVD) files for the ARM Cortex-M33F applications MCU in the nRF9160 SIP. Ozone comes bundled with a bunch of SVD files for different ARM cores, so we can provide a portable path to the file’s location by using the $(InstallDir) directory macro:

  • Project.AddSvdFile("$(InstallDir)/Config/CPU/Cortex-M33F.svd");

Since we’re debugging a Zephyr app, we can load the Zephyr RTOS awareness plugin automatically:

  • Project.SetOSPlugin("ZephyrPlugin.js");

File action functions

In addition, we need to provide Ozone with the path to the ELF file for the Zephyr app we’re trying to debug. We can use the $(ProjectDir) directory macro to provide a portable path to the ELF file relative to the directory containing the project file:

    • File.Open("$(ProjectDir)/build/zephyr/zephyr.elf");

Process replacement functions

In this example, we have a multi-image build for the nRF9160. We need to instruct the debugger to download the full merged image (not just the ELF). Ozone provides a set of process replacement functions that replace the default implementations of built-in debug operations. We can use the TargetDownload(); function to replace the default program download routine with one that loads the merged.hex file instead. Note that this also uses the $(ProjectDir) directory macro to provide a portable portable path to the merged image:

  • Exec.Download("$(ProjectDir)/build/zephyr/merged.hex");

Start the debug session

Now, click “File” → “Open…” and open the nRF9160.jdebug project file in Ozone.

Click on “Debug” → “Start Debug Session” → “Download & Reset Program” to start the debug session:

If you have multiple SEGGER devices plugged into your USB port, you’ll get a pop-up window asking which device should be used to flash the target:

If you don’t see the “Zephyr” window in the Ozone project, click on “View” → “Zephyr” to show the window:

That’s it!

You can relocate this file into any directory, including the git repository for your Zephyr app. Just make sure to update the relative paths in the file. Anyone who checks out the repo can quickly start a debug session without having to configure their own Ozone project.

Conclusion

Golioth can help you connect and secure your IoT devices, send sensor data to the web, update firmware over-the-air, and scale your fleet with an instant IoT cloud.

Try it today! You can make a small connected fleet and start sending data to and from the cloud immediately. Device management is free for individual users!

We are returning to Embedded World in 2024 (EW24) and will be showing off the things we’ve been working on at Golioth since last year. We’re also living a little closer to the edge and bringing some experiments and unreleased items to showcase on the floor. Demo gods, be kind!

We’ll be at the Zephyr booth, helping to showcase one of our favorite Real Time Operating Systems and Ecosystems (though not the only one we support!). Golioth generally only targets one part in our standard hardware setup, but we continuously verify a bunch of hardware on our Firmware SDK. This means that you can be certain that every new feature added to the Golioth Cloud and SDK is fully tested throughout our supported hardware. The great thing about Zephyr is that the underlying hardware works very similarly to all of our CVBs, because of the work from the silicon vendors that participate in the open source project. We’re excited because 2024 saw even more silicon vendors joining the fray!

Golioth Demos

Being part of a large project like Zephyr, we share time at the booth Kiosks. We’ll be at the Zephyr Booth (4-170) at the following times:

  • Tuesday, April 9th from 1500 to 1800
  • Wednesday, April 10th from 1200 to 1500
  • Thursday, April 11th from 0900 to 1130

All times CEST, which is GMT + 1

Hardware we’ll have on hand

  • Modbus Vibration monitor – This is our newest Reference Design that captures vibration and temperature data from a sensor normally used in industrial environments for large motors. The hardware in the Reference Design talks over RS-485 to the remote sensor and queries all of the available registers and publishes them to the Golioth cloud for processing and viewing.
  • Air Quality Monitor – It’s always interesting to see the trend lines of air quality metrics throughout the day. There are a lot of people that filter in and through the Nuremberg convention center, so we can track things like CO2 concentration just from the elevated number of bodies. The particulate counter is unlikely to go up a lot, but if there’s something like a cotton candy booth nearby, it could potentially have particulates flying through the air. I’ll be sure to go and investigate and clean up that particular air quality problem if the need arises.
  • Aludel Elixir – Powering our newer reference designs is the Aludel Elixir. This is an evolution of our previous designs (the Aludel Mini) that stitched together outside development boards that we loved like the Circuit Dojo nRF9160 Feather and the Sparkfun ThingPlus nRF9160. We pulled many of those components onto a bespoke PCB, and also added other components that can enhance any reference design. It all comes together in a custom milled case that enables maximum flexibility.

Aludel Elixir Rev B

Are you interested in your very own Aludel? Shoot me a note to discuss at Embedded World or fill out this form

Partner Demos:

AL2LOG at the AL2TECH booth (3A-335)

A render of the AL2LOG Unit

Our design partner AL2TECH based out of Italy is bringing an exciting new logging project based on the nRF9160 and an STM32 coprocessor. This is meant to target industrial applications that require a flexible way to capture data in a harsh environment.

The AL2LOG is a compact industrial logger with different sensor and actuator interfaces. This is based upon AL2TECH’s broad experience serving their clients in the energy meter/remote sensor monitoring industries.

The AL2LOG PCB (rev 1.0)

Some high level features include Cellular and GPS connectivity (nRF9160), as well as external module comms using USB-C, RS-485, and CAN. There is an Ultra Low Power acquisition and logging sub system (STM32) with a true 14 bit ADC. Industrial inputs including Digital Input, Dry Contact, Pulse Counter, 0-10V Voltage Analog Input, and 4-20mA Current Loop Input. There are outputs like Open Drain Output, and programmable supplies for devices downrange of the logger. The device can also switch external 220V via a relay. For powering the device you can use a 12-24V rail, or depend on the large D-Size High Power LTC Cells.

The device communicates back to Golioth using Zephyr/NCS and can be remotely updated using Golioth’s OTA service. Data routed from the field back to the cloud is accessible via the Golioth REST API.

BT Mesh demo from partner Ambient Sensors at the Zephyr booth (4-170)

BLE Mesh Demo from Ambient Sensors communicating through Golioth, on display at Embedded World

This demo shows Golioth controlling an LTE/BLE bridge (Thingy91) that communicates to a BLE Mesh composed of a series of lights that are running the Light Lightness Controller (the LC Server) model. Eight instances of the BBC micro:bit represent lights in this demo. The boards run BLE Mesh firmware on Nordic Semiconductor’s nRF52833, which could easily be controlling an LED driver instead of the demo LEDs.

The BLE SIG standard LC server code is running on each microbit, and is communicating with the Thingy91’s nRF52840, which communicates on the mesh as an LC client, Generic OnOff Client, and Light Lightness client. Using Golioth, the  demo remotely sends a command to turn the LC server on, and lights will then slowly dim over time (as is the functionality of the LC server). Normally lights dim after several hours, but for the purpose of the demo, we set that value to several seconds. Delay values may also be set via Golioth, showing how these settings can be tuned remotely if desired. Additionally, we have created commands to allow the Golioth user to turn on the lights, while turning off the LC Server (to prevent it from dimming the lights), and to set the lightness value to any desired value.

Golioth connectivity demo at the NXP FRDM Lab

Find Golioth at the FRDM Lab at EW24

NXP is another vendor that has great support in Zephyr. We’ll be showcasing Golioth’s solution on NXP boards at their FRDM Lab in the Messepark classroom (the main open area when you walk into the conference). You can also see all of NXPs new solutions at their main booth in the presentation hall, booth 4A-222.

Even more Golioth!

What’s that? You haven’t seen enough of us yet? You’d love to hear more on-site at Embedded World? Well let’s telegraph every place we’ll be! In addition to our time showcasing Golioth at the Zephyr booth, we’ll also be giving a couple of talks at the Zephyr stage (next to the Zephyr booth):

  • April 9th at 1400: “Building end-to-end Zephyr demos on IoT hardware”
  • April 10th at 1530: “Multi MCU OTA updates with Golioth and Simple Management Protocol”
  • April 11th at 1200: “Local toolchains, no more! Using GitHub Codespaces for training people on Zephyr throughout the world”

In the evenings (if we’re still standing), we plan to attend these open events and socialize with others in the industry:

  • IoT Stars – This is a short speaker event, as well as a networking session. We’ll have some of our portable demos with us.
  • PCBarts meetup – This is a more social event hosted by a local consulting and manufacturing company. Last year this was a wonderful group of engineers showing off their projects–personal and professional–after a long day at the tradeshow.

We really hope to see you at the conference! If you’d like to talk about Golioth and how we can work together, please fill out this form!

Timon Skerutsch is a software and electronics engineer who enjoys the systems design aspect of the work the most, from the cloud all the way down to silicon. He is the founder of the product development consultancy Diodes Delight.

Last year, I made the decision to do a personal prototype project with Zephyr instead of my go-to prototyping choices of Arduino, MicroPython, and CircuitPython. The latter two I still use a lot for rapid prototyping, as scripting languages like Python are hard to beat.

For the forthcoming project, I already knew where I was heading. I needed a sensor for my garden irrigation system that tracks the water level in my water reservoir. I had two requirements:

  • See the water level live on-site
  • Have the data transmitted to the internet so that I can see how things are doing while I’m away

The system regularly had leaks and failures in the irrigation pipes, which caused the automated watering pump to not only waste water but also fail to water my plants. This is detrimental during a heat wave! That added an additional requirement of an alarm to alert me of abnormal situations. When I started the project, I reached for Zephyr first. Let’s talk about why.

Why Arduino, anyway?

Change is a constant; no more so, than the early design phases of a product, when requirements rapidly shift. Prototyping is a crucial aspect of any development process and we often employ different tools for this than we do for our production firmware.

In the firmware world, the Arduino framework has been an immense success. Not only for teaching firmware development, but also as a quick and easy way to try out concepts and develop prototype solutions.

Not without controversy though. To this day, many embedded engineers will utter a silent curse on Arduino whenever it is encountered on the way to production. The supposed prototype firmware has morphed into the production firmware and now that needs to be extended with very complex functionality.

When deadlines are near and the stress levels are high, it is very appealing to companies to just keep using the code base that already seems to do 90% of the job. A lot of products end up shipping firmware based on frameworks like Arduino and then try to deal with the “last 10% of the work”. If you have developed software for a while you probably know those famous last 10% can be 90% of the work, completely derailing budgets and timelines.

But what is the issue? At the end of the day, Arduino is just a very light HAL based on C and C++! You can do whatever you could do in a bare metal C project. The emphasis is on “light”, which is very beneficial when you have only very basic requirements. Maybe you can get by just fine with printf() debugging and hitting that compile button in your IDE.

The Arduino HAL’s success was in part due to its simplicity and fully integrated development flow but it offers very few solutions to the modern challenges firmware developers are facing. When you consider the complexities you are faced with in modern devices, Over-the-Air firmware updates, firmware update encryption, Continuous Integration, connection to a cloud service, tracking of device status and metrics, then things start to look different.

Zephyr is changing things up in the industry

The Zephyr Project Real Time Operating System (RTOS) has seen a lot of adoption over the past years, even by Arduino themselves. They became a member of the Zephyr Project in 2023 and now contribute to the code base.

Zephyr is a very “IoT aware” RTOS and offers a lot of robust solutions to many of the very complex topics I mentioned. It is also one of the main targets of the Golioth Firmware SDK for that reason.

When developers first start interacting with Zephyr they often tend to be a bit intimidated. Device Tree and KConfig may be familiar tools for Embedded Linux developers, but not for someone coming from bare metal C or FreeRTOS. (Editor’s note: this is why Golioth offers free training around Zephyr).

Zephyr-specific tooling like the west meta tool means there’s a lot to learn when you start diving into Zephyr. You might start to question if that work is worth it. Especially early on in a development process where you want to move quickly and prove your concepts. You might feel a huge system like Zephyr could slow you down.

Due to the steep learning curve, Zephyr does not really have a reputation for being a tool for prototyping. But I think Zephyr has very much a place in that phase of a project and it comes with a lot of benefits once you move beyond the prototype: You are already in an environment that won’t hold you back when it comes to solving the tough problems of modern production ready firmware.

Now that I am up the (arguably steep) learning curve associated with Zephyr, I think in many cases I can produce a working solution a lot quicker than with Arduino or even MicroPython.

Not just for production grade firmware

Since I was starting a prototype, I chose an ESP32 dev board I had laying around which came with a nice little OLED screen. For the sensor, I opted for an industrial liquid level sensor. They are essentially pressure sensors in a sturdy form factor that measure the pressure differential of the outside air and the pressure seen in the liquid container.

I needed something rugged and precise to track abnormal water usage so that was a perfect solution. I ended up getting a stable 0.2mm resolution for my water column, much more than I needed. The sensor is a simple 4-20mA current loop that you often see in industrial automation and I connected that to an external precision ADC.

My firmware needs included:

  • WiFi provisioning
  • Network and application protocol to get the data to a server
  • OTA to update the device remotely
  • A GUI to show water levels on the OLED
  • ADC reads to ingest the sensor data

I opted to use Golioth for networking and OTA. While not a typical service for a hobby project, they have a (recently updated) free tier for individuals and it made the whole thing really easy. It only takes a couple lines of code to integrate into any Zephyr project and makes transmitting data to a database as easy as Serial.print(). Having OTA available is a matter of a KConfig option. Most importantly I don’t need to manage an internet facing server application!

net_connect();

golioth_client_t client;
const golioth_client_config_t* client_config = golioth_sample_credentials_get();
client = golioth_client_create(client_config);
golioth_client_register_event_callback(client, on_client_event, NULL);

err = golioth_lightdb_set_int_sync(client, "water-level", water_level/1000, 2);
if (err) {
    LOG_WRN("Failed to transmit water-level: %d", err);
}

I could have directly implemented CoAP or MQTT and host my own server for the receiving side. Both protocols are natively supported by Zephyr, which means I have flexibility if I change my mind on the server side in the future.

OTA firmware updates is also a concept native to Zephyr and very important: no matter what platform I choose! The Arduino ESP32 core has an option for OTA but if you are looking at any other MCU you would have to implement that from scratch which is a whole project in itself.
In Zephyr this is all enabled by the fantastic MCUBoot bootloader.

Abstractions are your friend in a complex world

The platform agnostic nature of Zephyr is powerful. Say you have already written a lot of code and then notice that your chosen MCU does not actually fulfill your needs. You don’t need to start from scratch because all of these advanced APIs are fully abstracted in Zephyr. You can retarget your code to a different platform with minimal code changes. The primary work will be in recreating your devicetree for the new hardware.

Arduino also is known for abstraction, but when it comes to more complex features the Arduino HAL is not defining an interface. Generally, you tend to need to stick to a particular platform if you want to take advantage of the underlying hardware’s fancy features, that is if they are available at all (in Arduino).

Lock-in with a specific IC is a painful lesson we all learned during the chip shortages of 2021 and 2022. Device Tree overlays are a great tool to stay on-top of changing hardware and describe those changes in a clean way. That flexibility is not only important from a risk perspective. Staying flexible during the prototype stage (where requirements change rapidly) allows you to try out different sensors and peripherals.

Changing a sensor in Zephyr is a matter of changing a dozen lines of devicetree definitions without needing to touch a single line of C code. This is made easier when the sensor is “in tree”, but it not the only way to use a new sensor. Devicetree also becomes a powerful tool in the early days of hardware development where your product might go through many revisions and changes. People on your team might be working with different hardware revisions but require the latest bug fixes.

This can quickly become tough to manage in the firmware if you had pin or even IC changes. No need for a ton of #ifdef‘s; all you need is a set of devicetree overlays that describe your various board revisions, the C code can most often stay the same. This not only makes your life easier but also helps reduce mistakes and stale code.

If you are still trying out options you can also interactively work with sensors through the Zephyr Shell, which makes for a great workflow to quickly try out several sensor candidates without writing firmware.

During my project I was unsure whether to choose a different MCU, because the built-in ADC of the ESP32 is quite noisy. In the end, I kept the ESP32 and chose to use an external ADC. My code did not have to change because the ADC API abstracts that away. It was just a matter of defining what ADC my project should use in the devicetree. My code does not need to care if that is an external I2C device or a peripheral internal to my MCU.

/{
    zephyr,user {
        io-channels =
            <&adc_ext 0>;
    };
};

&i2c0 {
    status = "okay";
    adc_ext: mcp3421@68 {
        compatible = "microchip,mcp3421";
        reg = <0x68>;
        #io-channel-cells = <1>;
    };
};

&adc_ext {
    status = "okay";
    channel@0 {
        reg = <0>;
        zephyr,gain = "ADC_GAIN_1";
        zephyr,reference = "ADC_REF_INTERNAL";
        zephyr,acquisition-time = <ADC_ACQ_TIME_DEFAULT>;
        zephyr,resolution = <18>;
        zephyr,differential;
    };
};

That is the benefit of fully abstracted subsystems, your application’s assumptions can stay the same most of the time. Last minute system changes are less painful during firmware development.

Complex UI’s don’t have to be complex to build

For the GUI, I went with LVGL, a popular UI framework that has been integrated into Zephyr.
That was probably the most eye opening experience to me. Normally you would have to mess with display drivers that all work very differently depending on the plugged in display. Then I would need to write code to manually transfer the rendered framebuffer to that display, which  again, tends to work differently with each display.

In Zephyr all I have to do is to modify the devicetree for which display driver my OLED needs, the resolution, and the bus it is connected to.

&spi3 {
    status = "okay";
    st7789v_st7789v_ttgo_128x64: st7789v@0 {
        compatible = "sitronix,st7789v";
        spi-max-frequency = <20000000>;
        reg = <0>;
        cmd-data-gpios = <&gpio0 16 GPIO_ACTIVE_LOW>;
        reset-gpios = <&gpio0 23 GPIO_ACTIVE_LOW>;
        width = <135>;
        height = <240>;
        x-offset = <53>;
        y-offset = <40>;
        vcom = <0x19>;
        rgb-param = [CD 08 14];
    };
};

With that done you can write powerful UIs with just a couple lines of code, all the hard stuff is handled behind the scenes. I figured the UI part would be the majority of work for this project, but ended up being done in under an hour.

Often Arduino prototypes tend to have character displays or use the same old school bitmap font because fonts are hard and font systems even harder. In LVGL, you have an array of modern fonts available and it’s fairly easy to include your own font.

Arranging elements is also trivial in LVGL. No need to manually calculate a bunch of stuff like your text length. It has a lot of functions available for laying out complex arrangements.
You can build some really pretty smartphone level UIs with it. These run on very constrained hardware and it doesn’t cost you your sanity in the process!

const struct device *display_dev;
display_dev = DEVICE_DT_GET(DT_CHOSEN(zephyr_display));

lv_obj_t *level_label;
lv_obj_t *status_label;
static lv_style_t level_style;
lv_style_init(&level_style);
lv_style_set_text_font(&level_style, &lv_font_montserrat_48);

level_label = lv_label_create(lv_scr_act());
lv_obj_align(level_label, LV_ALIGN_CENTER, 0, -20);

status_label = lv_label_create(lv_scr_act());
lv_obj_align(status_label, LV_ALIGN_BOTTOM_MID, 0, -50);
lv_obj_add_style(level_label, &level_style, 0);
// display the current water level
lv_label_set_text_fmt(level_label, "%llu", water_level/1000U);
lv_task_handler();

Quick, once you know how to get around

Within a day I had firmware for my hardware and it even looked…pretty!
Since its creation, my device has dutifully reported the water level and withstood the winter season.

The application is ~180 lines of C code, including a lot of error handling. That is really not a lot of code, for so much complex functionality. This is only possible thanks to all of the available abstractions that make writing the actual application logic a breeze. In the background there are multiple threads running but my code doesn’t even need to be aware of that. It is all handled by the kernel and the well-written libraries.

While simple things like an ADC read can be very verbose in Zephyr and a bit more complicated than in Arduino land, the hard parts–the things we often perceive as the last 10%–are a whole lot easier! You don’t want to start empty handed when you are tasked to implement encrypted firmware updates, OTA, telemetry or integrating the cloud team’s new backend system.

The grass is not always greener, of course. Zephyr is still comparatively young in embedded terms and while there are a lot of devices already supported, it is hard to beat the vast amount of drivers available for Arduino. In some situations you might want to do a first board bring up with an existing Arduino driver before implementing a Zephyr driver. License permitting, the driver code could be the basis for a port to Zephyr.

One reason why I think it is so common for firmware to get “stuck” in Arduino-land is because there has not been a good (free) alternative if you wanted to write C (or C++) and not pigeon hole yourself early on into one specific obscure vendor toolchain. If there is nothing obvious to move to, it can make the decision even harder and it will be put off until it’s usually too late.

Concepts like devicetree and a complex build system like CMake can be daunting at first, but there are ripe benefits at the end of the learning curve. If you want to learn Zephyr, Golioth regularly offers free Zephyr training sessions or you can read some of the great blog posts that cover the more gnarly bits of Zephyr in digestible bite sized portions.

Chris Duf is a chip-to-cloud software architect, working on embedded systems and IoT applications. He is the author of the DTSh tool.

Devicetree and the Devicetree Source Format (DTS) are major parts of Zephyr RTOS. But understanding the DTS output of an entire system—not to mention troubleshooting devicetree errors—can prove to be quite a challenge. This is especially true for beginners.

In this article, I’ll first discuss why the content of these DTS files is interesting, then introduce the Devicetree Shell (DTSh), a simple command line tool for visualizing the devicetree in a DTS, with versatile export capabilities.

Let’s do a quick demo before diving into the details. At build-time, during the configuration phase, Zephyr generates a devicetree that will represent the system hardware during the actual build phase. Two files are generated:

  • build/zephyr/include/generated/devicetree_generated.h: the devicetree in C, that describes the hardware to the device driver model
  • build/zephyr/zephyr.dts: the same devicetree in Devicetree Source Format (DTS), generated for debugging

DTSh can be used to present a much more human-readable view of these results:

The Devicetree Shell

find --with-bus * --OR --on-bus * -T --format NYcd

You can try this yourself, with the following in mind:

  • DTSh should install and run fine on GNU Linux (including WSL) and macOS with Python 3.8 to 3.11
  • on Windows, the readline API, on which DTSh relies for auto-completion and command history, is no longer distributed with the Python Standard Library: as a consequence, the user experience will be significantly degraded on this platform

Devicetree and Zephyr’s Driver Model

Devicetree is first a specification for a standardized data structure that can describe a system hardware and its initial configuration. Beside the DTS format we’ve already mentioned, a binary blob format is also defined (Flattened Devicetree, DTB).

Devicetree is primarily designed as a complete interface between a boot program like a bootloader and a client program like an operating system. When using Devicetree, Linux applies this approach (see Linux and the Devicetree):

  • the DTS for the system hardware is compiled to DTB, and linked into the vmlinux image
  • the boot program eventually passes a pointer to the devicetree in DTB format to the operating system client
  • the Linux kernel then walks through the devicetree to populate its device model, allocating device structures dynamically for the enabled DT nodes

While the hardware that the Linux kernel targets can benefit from this design, Zephyr targets embedded systems, which are more constrained, especially regarding persistent memory:

  • the binary blob is then wasted .rodata (typically Flash memory)
  • the kernel API needed to walk through the devicetree is wasted .text (also typically Flash memory)
  • the run-time overhead is worthless, most of the time device structures will be statically allocated

Zephyr has therefore chosen a different approach:

  • the devicetree is not passed to the Zephyr client program (everything happens at build-time)
  • only the device structures for enabled DT nodes are statically allocated into the .rodata section
  • the API to access these devices structures is entirely macro based, and does not end up in the .text section

Compared to Linux, we could say that the devicetree is passed to Zephyr in C format at build-time.

And, as a Zephyr application developer:

  • You use macros like DT_PATH or DT_NODELABEL to get DT node identifiers (this relies on the generated devicetree_generated.h, which is included by zephyr/devicetree.h)
  • Others like DEVICE_DT_GET to get pointers to the corresponding device structures

All this macrobatics is well explained in a presentation Marti Bolivar gave at a Zephyr Developer Summit in 2022: a few things have changed but still really worth watching.

So, why should I be interested in the DTS files content ?

A one sentence answer (well, two) could be:

  • Because the generated DTS will always describe the whole system hardware from the board files (the .dts and .dtsi files, plus possible overlays), including disabled devices and buses
  • Since the DTS file is generated early during the configuration phase, chances are that it will exist even when the build eventually fails: here, checking the devicetree content will prove helpful in debugging common issues (you know, the DT_N_S_ and __device_dts_ord_ things)

Well, but then what application can I use to open this DTS file, other than a text editor?

DTSh is just that: a simple tool to navigate, visualize and search a devicetree described in a DTS file, along with the bindings that specify and document its content.

In the remainder of this article, we’ll install DTSh before we reconsider this question with a new tool on hand.

Install DTSh

For simplicity, the examples in this article will assume DTSh is installed alongside your Zephyr development environment (please refer to DTSh’s Getting Started Guide for details about installation methods): just enter pip install dtsh from the same prompt where you usually run west commands.

You should now be able to open DTS files in the Devicetree Shell, e.g.:

$ cd zephyr/samples/sensor/bme680
$ west build
$ dtsh
dtsh (0.2rc1): Shell-like interface with Devicetree
How to exit: q, or quit, or exit, or press Ctrl-D

/
> ls -l
 Name              Labels          Binding
 ───────────────────────────────────────────────────────
 chosen
 aliases
 soc
 pin-controller    pinctrl         nordic,nrf-pinctrl
 entropy_bt_hci    rng_hci         zephyr,bt-hci-entropy
 sw-pwm            sw_pwm          nordic,nrf-sw-pwm
 cpus
 leds                              gpio-leds
 pwmleds                           pwm-leds
 buttons                           gpio-keys
 connector         arduino_header  arduino-header-r3
 analog-connector  arduino_adc     arduino,uno-adc

In the above example:

  • no need to pass the DTS file path to DTSh: by default it will try to open the devicetree at build/zephyr/zephyr.dts, which the preceding west build command has just generated
  • no need to tell where to search for the YAML binding files: DTSh first tries to retrieve this information from a CMake cache at build/CMakeCache.txt, which should also exist

As you can see, it really presents itself like a shell: a prompt where you enter commands like cd, ls or find, but these operate here on device paths rather than on file system paths. And, as with a shell, you can redirect commands output to files.

Only a few principles are necessary to start using DTSh:

  • You can navigate the devicetree (change the current working branch) with the cd command like a hierarchical file system
  • Device paths can be absolute path names or relative paths from the current working branch, may start with DTS labels and support some globbing
  • By default, commands will output paths to represent nodes, just like their Unix homonyms represent files or directories (ls, find and tree); the --format FMT option will instead format the output to show the information you’re looking for (-l is a shortcut for a configurable default format)
  • Command output redirection also uses the POSIX syntax, e.g. tree -lR > devicetree.html (the file extension determines the format)
  • For a better default user experience, prefer a dark Terminal theme and run the shell full-screen or in a maximized window
  • Last but not least, don’t be afraid to press the TAB key twice: it will trigger contextual auto-completion from nearly everywhere

A word of advice: if a command line tool looks scary, don’t worry. The Devicetree Shell syntax is simple and consistent, and command line auto-completion and history will save you from both memorizing and typing most things.
The DTSh handbook provides detailed documentation and various examples.

Back to DTS files

Let’s go back to the use cases we put forward:

  • Quickly learn about a new hardware configuration
  • Debug mysterious Devicetree issues

Learn about Hardware Configurations

When starting a new project, or porting an existing application to another board, it’s nice to get some visual representation of what’s available to your program.

Let’s say you’re interested in the nRF52840 DK (nrf52840dk_nrf52840), which you haven’t yet used with Zephyr.

First, generate the corresponding devicetree, then open it in dtsh:

# Any Zephyr sample that supports the board would do just fine.
cd zephyr/samples/sensor/bme680

# Remember, the configuration phase is enough.
cmake -B build -DBOARD=nrf52840dk_nrf52840

# No need to pass arguments, dtsh will open build/zephyr/zephyr.dts
dtsh

Try the command tree --format NKYC: it will dump the whole devicetree as a detailed tree view, with all device labels and alias (Also Known As), buses and bindings, ending with something like in the screenshot below.

Devicetree as tree view

tree --format NKYC

You have probably noticed:

  • Some nodes appear dim: these are the disabled buses and devices
  • Most of the time, the content of the Binding column appears with a (possibly dashed) underline: these are hyperlinks to the corresponding binding files, hovering over the text will reveal their paths, and clicking while holding the Ctrl key will open them in with your default application for handling YAML files
  • The content of the Binding column may also be anchored to its parent: these are child-bindings specified in the same YAML file

But the most blindingly obvious was probably that the command literally dumped its output, making impossible to understand the tree view calmly before it disappears. This can be addressed in two ways:

  • Try tree --format NKYC --pager: this will pass the command output to the system pager, where you can take your time (press h to display the pagers’ help screen, q to exit the pager and return to the dtsh prompt)
  • You can also export the tree view to an HTML file, e.g. tree --format NKYC > nrf52840dk_nrf52840.html

Another similar use case could consist of finding some information without having to resort to the SoC’s datasheet. You may not have the datasheet readily available, nor do you want to have it littering your desk.

The size and base addresses of the different kind of available memory is typically something you can forget, especially if you work with a handful of boards.

/
> find -E --also-known-as (image|storage).* --format NLrd > memory.txt

/
> find --also-known-as ram -i --format NLrd >> memory.txt

You now have a simple and nice memory.txt file:

Name             Labels             Registers         Description
──────────────────────────────────────────────────────────────────────────────────────────────────────────────
partition@c000   slot0_partition    0xc000 (472 kB)   Each child node of the fixed-partitions node represents…
partition@82000  slot1_partition    0x82000 (472 kB)  Each child node of the fixed-partitions node represents…
partition@f8000  storage_partition  0xf8000 (32 kB)   Each child node of the fixed-partitions node represents…

Name             Labels  Registers            Description
──────────────────────────────────────────────────────────────────────────────
memory@20000000  sram0   0x20000000 (256 kB)  Generic on-chip SRAM description

Tip: find supports a handful of criteria to match devicetree nodes with. To get the full list, start a command line with find --, then press TAB twice. The auto-completion will enumerate all the options that have a long name (short option names begin with a single -): the criteria are those starting with --with unless another term really seems more natural, e.g. --also-known-as or --on-bus.

/
> find --[TAB][TAB]
-h --help                      print command help
--also-known-as PATTERN        match labels or aliases
--chosen-for PATTERN           match chosen nodes
--count                        print matches count
--enabled-only                 filter out disabled nodes or branches
--format FMT                   node output format
--NOT                          negate the criterion chain
--on-bus PATTERN               match bus of appearance
--OR                           match any criterion instead of all
--order-by KEY                 sort nodes or branches
--pager                        page command output
--with-alias PATTERN           match aliases
--with-binding PATTERN         match binding's compatible or headline
--with-binding-depth EXPR      match child-binding depth
--with-bus PATTERN             match supported bus protocols
--with-compatible PATTERN      match compatible strings
--with-description PATTERN     grep binding's description
--with-device-label PATTERN    match device label
--with-dts-ord EXPR            match dependency ordinal
--with-irq-number EXPR         match IRQ numbers
--with-irq-priority EXPR       match IRQ priorities
--with-label PATTERN           match node labels
--with-name PATTERN            match node name
--with-path PATTERN            match path name
--with-reg-addr EXPR           match register addresses
--with-reg-size EXPR           match register sizes
--with-status PATTERN          match status string
--with-unit-addr EXPR          match unit address
--with-unit-name PATTERN       match unit name
--with-vendor PATTERN          match vendor prefix or name

DTS labels often match names in the SoC’s documentation:

/
> ls &[TAB][TAB]
acl                  Nordic nRF family ACL (Access Control List)
adc                  Nordic Semiconductor nRF family SAADC node
arduino_adc          ADC channels exposed on Arduino Uno (R3) headers…
arduino_header       GPIO pins exposed on Arduino Uno (R3) headers…
arduino_i2c          Nordic nRF family TWI (TWI master)…
arduino_serial       Nordic nRF family UARTE (UART with EasyDMA)
arduino_spi          Nordic nRF family SPIM (SPI master with EasyDMA)
boot_partition       Each child node of the fixed-partitions node represents…
button0              GPIO KEYS child node
... stripped ...

/
> ls &button0 -ld
Name      Labels   Binding
───────────────────────────────────────
button_0  button0  GPIO KEYS child node

/
> ls &timer0 -ld
Name            Labels  Binding
────────────────────────────────────────
timer@40008000  timer0  nordic,nrf-timer

/
> ls &i2c0 -ld
Name          Labels             Binding
───────────────────────────────────────────────
i2c@40003000  i2c0, arduino_i2c  nordic,nrf-twi

Debug Devicetree Issues

We are now equipped to look again at these mysterious DT_N_S_ and __device_dts_ord_ things.

Let’s start by disabling the I2C bus in boards/nrf52840dk_nrf52840.overlay to intentionally introduce a build error:

&i2c0 {
  status = "disabled";
  bme680@76 {
    compatible = "bosch,bme680";
    reg = <0x76>;
  };
};

west build will fail with one of these mysterious errors:

$ west build

... stripped ...

 from zephyr/drivers/sensor/bme680/bme680.c:14: error: '__device_dts_ord_124'
 undeclared here (not in a function); did you mean '__device_dts_ord_14'?
 89 | #define DEVICE_NAME_GET(dev_id) _CONCAT(__device_, dev_id)
    |                                         ^~~~~~~~~

... stripped ...

FATAL ERROR: command exited with status 2: /usr/bin/cmake --build zephyr/samples/sensor/bme680/build

First, you need to know that __device_dts_ord_124 reads “the device with dependency ordinal 14”, where the dependency ordinal is a non-negative integer value such that the value for a node is less than the value for all nodes that depend on it.

Knowing how to read C tokens like DT_N_S_soc_S_i2c_40003000 is also useful:

  • DT_N reads “devicetree node” (DT node)
  • _S_ represents the / that separates node names
  • DT_N_S_soc_S_i2c_40003000 is then the C token for the node with path name /soc/i2c@40003000

And indeed, if your search devicetree_generated.h for DT_N_S_soc_S_i2c_40003000, you’ll eventually come across the lines below (scattered among more than ten thousand):

#define DT_N_S_soc_S_i2c_40003000_ORD 124
#define DT_N_S_soc_S_i2c_40003000_STATUS_disabled 1
#define DT_N_S_soc_S_i2c_40003000_S_bme680_76_ORD 125
#define DT_N_S_soc_S_i2c_40003000_S_bme680_76_REQUIRES_ORDS 124

Which should help you conclude that the I2C bus the BME680 sensor should connect to is actually disabled.

Compare this to what DTSh can tell you with a single command line:

/
> find --with-dts-ord 124 --format psTd
Mysterious build error

A not so mysterious issue.

Epilogue

You should now be able to:

  • Open DTS files that represent your hardware configurations (hint: cd myproject && cmake -B build -DBOARD=myboard && dtsh)
  • Navigate (cd) and visualize (ls, tree) the devicetree
  • Experiment with find --[TAB][TAB] to search for buses, bindings, interrupts, and more
  • Experiment with the --format --[TAB][TAB] option to see the information you’re interested in
  • Experiment with command output redirection to text, HTML and SVG (hint: find --with-bus * --OR --on-bus * -T --format NYcd > buses.svg)
This brief introduction to DTSh misses interesting topics, don’t hesitate to skim through the documentation to find:
  • More usage examples
  • How to configure DTSh behavior and appearance with preferences and theme files
  • Learn more about the command line interface, auto-completion and history
  • A summary of useful key bindings (hint: Up and Down move backward and forward through the command history, respectively)
  • A detailed description of the built-in commands, their options and parameters

And remember, auto-completion (pressing TAB twice) is your friend, and can even list the available commands:

/
> [TAB][TAB]
alias     list aliased nodes
cd        change the current working branch
chosen    list chosen nodes
find      search branches for nodes
ls        list branch contents
pwd       print path of current working branch
tree      list branch contents in tree-like format

RFC: DTSh: DTS file viewer with a shell-like command line interface is a proposal to upstream the Devicetree Shell as a new Zephyr extension to West, such that you would eventually be able to just run with:

$ west build
$ west dtsh

This is the appropriate place to comment on: the potential usefulness of such a tool, the acceptability of the command line approach for beginners, the features you found interesting and those you would like to see added (accessing arbitrary node properties is definitely a miss), or the technical reasons why you think it is a good idea, or not, to upstream DTSh as a new West command. This is not the appropriate place to report bugs, though. Please open issues on the DTSh project instead.

Nordic’s nRF9160 cellular modem includes a great peripheral called the Key Management Unit (KMU). This secure key storage mechanism lets you write keys to it which cannot be read back. However, they can still be used for DTLS authentication. In this video and blog post I’ll walk you through how to use the feature with the newest release of the Golioth Firmware SDK.

Overview of secure storage and TLS Tag authentication

With the v0.10.0 release of the Golioth Firmware SDK, credentials may be selected using the TLS secure tag. One example of hardware that embraces this is the Nordic nRF9160, which implements Zephyr’s TLS credential management API. Credentials (either x509 certificates or pre-shared keys) are stored on the device using a security tag. Pass that tag to the Golioth Firmware SDK and enable offloaded DTLS sockets in order to utilize those securely stored secrets.

Since these credentials are stored separately from firmware, they are persistent and you can store multiple different credentials. At runtime, pass the security tag as a parameter when creating the Golioth client and you’re all set.

How to store credentials on the nRF9160

Storing credentials on the nRF9160 is accomplished in two steps: first generate and prepare the credentials, then place them on the device using AT commands. (Don’t worry, there are helper tools to generate the AT commands for you.)

Generating Certificates

Golioth has long supported certificate authentication. You can follow the Certificate Authentication guide in our Docs. You will need to use the .pem version of the device certificate and key, and you’ll also need the root certificate from the CA that issued Golioth’s server certificate (we use LetsEncrypt.org).

  1. Generate the root certificate and device certificate by following the docs page.
  2. Download the CA certificate from Let’s Encrypt

Now upload the public root certificate you generated (golioth.crt.pem) to Golioth so it may be used to authenticate your device. From the left sidebar choose Project Settings, select the Certificates tab, and click Add CA Certificate:

Upload public root certificate to Golioth

Generating PSK Credentials

You should not use PSK credentials for production purposes, certificates are far more secure. However, for demonstration purposes, here’s what you need to do to prepare your PSK:

  1. Use the Golioth console to add a new device.
  2. Copy the PSK-ID and PSK from your newly generated device.
  3. Use the following command to format your PSK as a HEX string—the format required by the nRF9160 (note this is only for the PSK, not for the PSK-ID).
echo "your-psk-here" | tr -d '\n' | xxd -ps -c 200

Loading Credentials onto the nRF9160

  1. Build and flash the Nordic at_client sample onto your device.
  2. Use the Nordic nRF Connect for Desktop tools to write credentials to the device.
    1. Older versions of this tool will use the LTE Link Monitor, newer versions will use the Cellular Monitor.
    2. Choose the security tag you wish to use.
    3. Add your credentials to the interface and use the Update certificates button to write to the device. I found that I wasn’t able to write all three certificate artifacts at the same time and instead needed to enter them one at a time.

Nordic Cellular Monitor used to store device credentials on nRF9160

The credentials are stored using AT commands over a serial connection. You do not need to use the Nordic desktop tools if you don’t care to as the commands can be sent from any serial terminal connection.

Configure Golioth to locate credentials by tag

Now that our credentials are stored on the device, it is a trivial process to adapt the Golioth client to use them. In the video, I stored my certificates at security tag 24. I simply pass this to my application by adding the following Kconfig symbols to the prj.conf file:

CONFIG_GOLIOTH_AUTH_METHOD_CERT=y
CONFIG_GOLIOTH_SAMPLE_AUTH_TYPE_TAG=y
CONFIG_GOLIOTH_COAP_CLIENT_CREDENTIALS_TAG=24

(If you are testing PSK authentication instead of certificates, do not use the Kconfig symbol that sets CERT as the auth method. Without it, PSK will be selected by default.)

You must also remove one symbol from the boards/nrf9160dk_nrf9160_ns.conf file. This symbol tells the application to skip the offloaded DTLS sockets, however, that’s exactly the feature we want when using tag-based credential selection. Remove this line to re-enable socket offloading:

# Remove this line from nrf9160dk_nrf9160_ns.conf
CONFIG_NET_SOCKETS_TLS_PRIORITY=35

With that in place, compile the application and flash it to your nRF9160. It will now use the stored credentials to authenticate with Golioth.

Understanding the Golioth client config

The Golioth samples are configured to use a common library that configures the Golioth client on your behalf. However, the configuration process is very simple as I demonstrated it in the video.

Create a config struct that chooses TLS tags. Use the struct to pass the security number where the credentials are stored. Here’s what that would look like for my credential authentication example:

/* Config for credential tag authentication */
struct golioth_client_config client_config = {
    .credentials =
        {
            .auth_type = GOLIOTH_TLS_AUTH_TYPE_TAG,
            .tag = 24,
        },
};

client = golioth_client_create(&client_config);

Device Credentials with Golioth

The new APIs present in the Golioth Firmware SDK make it really easy to select credentials using tags. We’d love to hear how you plan to utilize this functionality. Show off your project on the Golioth Forum, or hit us up at the DevRel email!

Zephyr has a lot of tricks up its sleeve and most recently I used it to enable power regulators on a custom Golioth board. Perhaps the most interesting part of this is that it can be done entirely with the configuration code, without needing to dive in to any of the C files. And as the icing on the cake, Zephyr even includes interactive shell for working with regulators!

If you’ve been following our blog for a while, or you’ve checked out our growing library of reference designs, you’ll know that we’ve been using an internal hardware platform codenamed “Aludel” for rapid prototyping. Chris Gammell has been busy working on a new version of the Aludel main board with the ability to shut off power to the mikroBUS Click board sockets for low-power operation.

For example, a GPIO from the onboard nRF9160 SIP is connected to the EN pin on the +5V boost regulator. This grants Zephyr firmware the power (ha!) to enable or disable the regulator:

When the first prototype boards arrived from the manufacturer, we needed to enable these power regulators as part of the hardware bring-up process. I was pleasantly surprised to discover that this is actually possible to do entirely with Devicetree & Kconfig without writing any C code!

Zephyr’s regulator bindings

Out of the box, Zephyr provides regulator-gpio and regulator-fixed devicetree bindings for variable and fixed-voltage regulators respectively. These bindings are used to define GPIO-controlled power regulators that can be enabled automatically when the OS boots.

Here’s the devicetree node we’re using for the +5V boost regulator on the Aludel board:

reg_mikrobus_5v: reg-mikrobus-5v {
    compatible = "regulator-fixed";
    regulator-name = "reg-mikrobus-5v";
    enable-gpios = <&gpio0 4 GPIO_ACTIVE_HIGH>;
    regulator-boot-on;
};

The compatible property matches this node to Zephyr’s regulator-fixed device tree binding, and the regulator-name property is just a descriptive name for the regulator output.

Next, the enable-gpios property is a phandle-array devicetree property which defines the GPIO connected to the regulator’s EN pin:

  • &gpio0 is the phandle for the GPIO0 controller node that controls the pin
  • 4 is the pin number on the controller
  • the pin is configured with the GPIO_ACTIVE_HIGH flag because the regulator EN pin is an active-high input

The regulator-boot-on property tells the regulator driver that the OS should turn on the regulator at boot (but shouldn’t prevent it from being turned off later). We just needed to set the following Kconfig symbol to enable the regulator drivers:

CONFIG_REGULATOR=y

Regulator shell

When you’re bringing up a new board, it’s really helpful to have full control over the power regulators from a diagnostic shell. Zephyr provides a regulator shell that allows you to interact with regulators on your board via the shell interface!

Set the following Kconfig symbols to enable the regulator shell:

CONFIG_SHELL=y
CONFIG_REGULATOR=y
CONFIG_REGULATOR_SHELL=y

With the regulator shell enabled, you can enable/disable the regulator. You can also get/set parameters like voltage, current limit, and operating modes.

Regulator shell example

First, we need to get the device node for the regulator. You can list the available devices and their states using the device list shell command:

uart:~$ device list
devices:
- nrf91_socket (READY)
- clock@5000 (READY)
- gpio@842500 (READY)
- psa-rng (READY)
- uart@9000 (READY)
- uart@8000 (READY)
- flash-controller@39000 (READY)
- i2c@a000 (READY)
- reg-mikrobus-5v (READY)
- reg-mikrobus-3v3 (READY)

To disable the reg-mikrobus-5v regulator, we can run the following shell command:

uart:~$ regulator disable reg-mikrobus-5v

To enable the reg-mikrobus-5v regulator again, we can run a similar shell command:

uart:~$ regulator enable reg-mikrobus-5v

Time to hit that play button on some Warren G!

🎵 “Regulators, mount up!” 🎵

Learn more about the Zephyr shell

Controlling power regulators is just one of the neat things you can do with the Zephyr shell. At Golioth we think the Zephyr shell is fantastic and we’ve written extensively about it on our blog. We also use it in the Golioth SDK for things like setting device credentials.

If you’d like to learn more about Zephyr in general, join us for a free Zephyr training. Our next session is coming up in February. Sign up now!

In the last blog post about the PPK2,we explained operating modes for embedded devices and how current consumption is generally measured. With Nordic’s Power Profiler Kit II, we were successful in reducing the current draw of Golioth’s hello sample by a factor of 10 by simply turning the modem off. But, truth be told, 4mA is still a significant current draw for battery-operated devices in Standby mode. The aim for today is to lower the current consumption even more.

General Power Saving Recommendations

Let’s discuss some general recommendations for lowering current consumption. Every device/product has a set of constraints. From the sensor reading period to the number of sensors connected to the MCU, the current consumption for your particular device may vary based on which function you are performing and how much you are asking of your device.

Disable Unused peripherals

Some peripherals are enabled by default, depending on the devicetree of the board you are using. Peripherals that are not in use should be disabled in the overlay file. Even though it might not seem obvious at first,  some peripherals could potentially draw current just by being enabled. And the result could be milliamps of unnecessary current draw.

Peripherals are enabled or disabled in the device overlay file. For the hello sample, we won’t use any of the peripherals, and we’ll disable them all in the nrf9160dk_nrf9160_ns.overlay file.

You only need to disable the peripherals which are not utilized in your project. You can use the Device Power Management module to put peripherals into sleep mode in inactivity periods; more about that later on.

Disable Serial Logging

By default, logging is performed over the serial port associated with the UART(E) peripheral with Nordic SoCs. If a device is expected to work without human interaction over the serial port, then there is no need for logging over serial output and having the associated current consumption. By doing this, we can reduce the current consumption by ~1mA.

  • Disable serial output with: CONFIG_SERIAL=n
  • Disable serial logging with: CONFIG_LOG=n
  • Disable the UART console with: CONFIG_UART_CONSOLE=n

For the purposes of the hello sample, we won’t disable the logging subsystem because we want the log messages to be sent to Golioth’s Logging device service, but we have disabled the uart0 peripheral, which is used as a serial console by default.

Enabling Device Power Management

The idea behind the Device Power Management module is to allow device drivers to handle power management operations. For instance, it turns off clocks and peripherals, lowering the current consumption. The Device PM module provides an interface that the device drivers use to be informed about entering the suspended state or resuming from the suspended state. This enables the application developer to suspend peripherals when the CPU goes to sleep, depending on the application’s behavior.

For example, we can turn of an SPI peripheral while it is not in use to reduce the current draw. A device driver must have an implementation of the PM action callback used by the PM subsystem to suspend or resume devices.

Since we won’t use any of the nRF9160 SoC peripherals in the hello sample, we won’t see any benefit from using the Device PM. Nordic’s documentation explains how to utilize the PM module on the external flash case.

Results

As in the previous blog post, we are going to connect to the cellular tower, Golioth Cloud, and send 5 hello messages; afterward, we’ll stop the Golioth system client and call the lte_lc_offline API function, which sets the device to flight mode, disabling both transmit and receive RF circuits and deactivating LTE and GNSS services.



From the picture above, we achieved an average current of 2.69 µA when all peripherals are disabled, the modem is turned off, and the CPU is in IDLE. It’s up to the application developer to decide when to enter this minimal operating state, and deal with the consequences when coming back online after this deep sleep. Things like ConnectionID can help cellular devices save power on handshakes with the tower when re-connecting.

Conclusion

We showed how disabling unused peripherals can benefit our current consumption bottom line and save milliamps in the process by achieving ~3uA current draw. In the next blog post, we’ll talk about Power Optimizations specific to the nRF9160 SoC and how to use Power Saving Mode (PSM) with the modem and eDRX method instead of turning the modem off completely.
