It’s no secret that we like Zephyr Real Time Operating System (RTOS) around here. Nor is it a secret that we’re very interested in the Internet of Things (IoT). Golioth Founder and CEO Jonathan Beri gave a talk at the 2022 Zephyr Developer Summit (ZDS) about why those two things are a perfect match, and how Zephyr can help you create an IoT product faster.

A high level overview

Since this talk was on the first day of ZDS, it was focused on people less familiar with the Zephyr ecosystem. So what should a beginner know about Zephyr and its relationship to IoT devices?

Batteries are included

Zephyr has a couple of key features that makes it a “one stop shop” for building an IoT device. Some other RTOSes rely on the engineer to piece together libraries and implementations to get started, which either means more startup time or reliance on hardware vendors to make a ready-to-go solution for you. Instead, Zephyr provides individual elements already configured to work together:

  • Device drivers
  • An OS kernel (including scheduler)
  • Services
  • A build system

Tying together the ecosystem with these tools provides a consistent experience. This also leads to another very important aspect.

Chip vendor buy-in

Because Zephyr has a well defined system, the chip vendors develop code to make their parts work within the ecosystem. With other RTOSes, that script is flipped; the RTOS is made to work with abstraction layers within the vendor specific ecosystem, meaning there is less likelihood of interoperability with other vendor solutions.

In addition to the chipsets from the vendors, a wide range of boards are supported. Targeting specific boards makes it easier to get dev boards working when getting started, and remapping pins to specific functions on a board doesn’t require a configurator tool like those available in many vendor IDEs.

Talking to the Internet

If you choose an RTOS that isn’t a broader ecosystem, you need to either define your own network layers or lean on a vendor implementation to do it for you. In Zephyr, the network layer and the protocol definitions are done as a part of the community. That means that chip, module, and software vendors are all working towards a common implementation. Add in the fact that there are modems and abstraction layers all the way up the stack, and an engineer using Zephyr doesn’t need to think about all of the pieces it takes to connect to the internet. At Golioth, we are able to switch between various networking technologies easily when using Zephyr.

Protocol Variety

Golioth talks to the internet at a very high level, so network access “just works”. This comes into focus as a small embedded device can talk to the variety of internet protocols available. Most people understand HTTP, but also consider the more common IoT favorites like MQTT and CoAP. Golioth favors CoAP but also supports MQTT. This enables implementations in other parts of the network stack. A good example is devices running OpenThread, a Thread network protocol implementation. As we showed in our recent post about Thread, a small Zephyr-based device utilizes 6LoWPAN and talks over CoAP using UDP packets to talk back to the Golioth cloud.

Last but not least: Security

Zephyr enables a secure connection back to the internet through the network stack and with features like DTLS, the basis of a secure connection over UDP. Security is a deeper topic in Zephyr though, all the way down to secure bootloaders and working within things like TrustZone. Talking to secure elements requires drivers that understand how to communicate with particular chip features (internal or external to a microcontroller). At a very high level, Zephyr focuses on things like Software Bill of Materials (SBOM), so your security teams understand the various software you are pulling into the build.

Built for IoT

Zephyr not only ❤️ internet…it’s purpose built for enabling IoT devices. Paired with Golioth, a Zephyr device has a higher likelihood of getting to market and growing to a massive scale. We’d love to hear your thoughts about the video on our Forum, our Discord, or by email.



Founding Engineer of Golioth, Alvaro Viebrantz went to the Zephyr Developer Summit…and said the hardware isn’t the only part of an IoT system that matters. That’s bold! This was a room full of hardware and firmware designers!

In reality, this talk is about everything else you should consider when building a device using the Zephyr Real Time Operating System (RTOS). Alvaro goes through the many layers and considerations when architecting large scale Internet of Things (IoT) deployment, from the servers, to the apps, to how devices are communicating back to the cloud, and yes, all the way down to the code put onto the end device.

Top Down Design

Most IoT users first experience a device not from holding the hardware in their hand and seeing it do some particular action. Instead, users rely on things like Dashboards and Applications. The physical device is often hidden from the end user, at least inside an enclosure, and sometimes entirely (as in the case of something like a home monitor in your attic).

It’s important to start by mapping your data model, often before you even start your first schematic. What will your device do? How will it be accessed hierarchically? What other elements are part of the system or will be in the future?

Also important, you should follow the ownership of both the physical device and that device’s output data all the way up the chain back to the user. How will a user claim a device belongs to them? How will you organize the various levels of permission required? What kind of questions will your users seek to answer with the end device or with the entire fleet? (ie. “Do any vehicles in the fleet have low battery?”)

Who is in charge here?

After you have considered how you will configure your database and what the end user will see when they are interacting with data, you should move on to access levels and which parts of the system are accessible by different individuals. This may include access to the end application, but should also include access control to the configuration components of the system. You don’t want your end users to be able to access your device management console, even if they are the ultimate owner of the device. Instead, you will want to provision the devices so you know the unique identifiers of the end-device, and then assign that and the access level to the user.

Additional layers required for a realistic IoT deployment

As you continue to move “down the stack” from Applications all the way to the hardware, there is still a good chunk of Cloud in between. You’ll want to make sure you at least understand all of the elements you’ll likely want in your design, including:

  • Device management
  • Device state and configuration
  • Bidirectional command and control
  • Time-series data and events

Connecting to the network

We’re almost down at the device itself, but the connection to the network is another key consideration before we get there. Not just the method of connection (which ultimately relies on the hardware), but also the protocol and the pathways of each packet coming back. In Golioth’s case, we default to CoAP, which is a lower overhead, UDP based protocol. All of our device SDKs include support to make it easy to talk to CoAP endpoints on the Golioth servers. As Alvaro mentioned in his talk, and as our SDKs also feature, encoding can help to shrink messages even further, using things like protobuf, JSON, and CBOR.

Finally the hardware

By this point in the room, we were squarely back into the realm of expertise of Zephyr developers, though many now had a greater appreciation of all the other things required for IoT systems. Alvaro mentioned how some of the interaction of the connectivity on-device in Zephyr could affect your decision making further up the stack. This talk to a packed room showed developers how to plot out a successful IoT deployment beyond the limits of the hardware, and to think about IoT systems from the hardware, all the way up to the end user.



Controlling 10 devices is easy, controlling 10,000 is a different story. The trick is to plan for scale, which is what we specialize in here at Golioth.

A few weeks ago we announced the Golioth Device Settings Service that enables you to change settings for your entire fleet at the click of a button. Of course, you can drill down to groups of devices and single devices too. While the announcement post showed the Settings Service using our ESP-IDF SDK, today we’ll look at this setting service from the device point of view with Zephyr RTOS.

Device-side building blocks

The good news is that the Golioth Zephyr SDK has done all the hard work for you. We just need to do three things to start using the settings service in any Zephyr firmware project:

  1. Enable the settings service in KConfig
  2. Register a callback function when the device connects to Golioth
  3. Validate the data and do something useful when a new setting arrives

Code walk-through

Golioth’s settings sample code is a great starting point. It watches for a settings key named LOOP_DELAY_S to remotely adjust the delay between sending messages back to the server. Let’s walk through the important parts of that code for a better understanding of what is involved.

1. Enable settings in KConfig

CONFIG_GOLIOTH_SETTINGS=y

To turn the settings service on, the CONFIG_GOLIOTH_SETTINGS symbol needs to be selected. Add the code above to your prj.conf file.

2. Register a callback for settings updates

static void golioth_on_connect(struct golioth_client *client)
{
    if (IS_ENABLED(CONFIG_GOLIOTH_SETTINGS)) {
        int err = golioth_settings_register_callback(client, on_setting);

        if (err) {
            LOG_ERR("Failed to register settings callback: %d", err);
        }
    }
}

To do anything useful with the settings service, we need to be able to execute a function when new settings are received. Register the callback function each time the device connects to Golioth. Your app may already have a golioth_on_connect() function declared, look for the following code at the beginning of main and add it if it’s not already there.

	client->on_connect = golioth_on_connect;
	client->on_message = golioth_on_message;
	golioth_system_client_start();

Each time the Golioth Client detects a new connection, the golioth_on_connect() function will run, which in turn registers your on_setting() function to run.

3. Validate and process the received settings

enum golioth_settings_status on_setting(
        const char *key,
        const struct golioth_settings_value *value)
{
    LOG_DBG("Received setting: key = %s, type = %d", key, value->type);
    if (strcmp(key, "LOOP_DELAY_S") == 0) {
        /* This setting is expected to be numeric, return an error if it's not */
        if (value->type != GOLIOTH_SETTINGS_VALUE_TYPE_INT64) {
            return GOLIOTH_SETTINGS_VALUE_FORMAT_NOT_VALID;
        }

        /* This setting must be in range [1, 100], return an error if it's not */
        if (value->i64 < 1 || value->i64 > 100) {
            return GOLIOTH_SETTINGS_VALUE_OUTSIDE_RANGE;
        }

        /* Setting has passed all checks, so apply it to the loop delay */
        _loop_delay_s = (int32_t)value->i64;
        LOG_INF("Set loop delay to %d seconds", _loop_delay_s);

        return GOLIOTH_SETTINGS_SUCCESS;
    }

    /* If the setting is not recognized, we should return an error */
    return GOLIOTH_SETTINGS_KEY_NOT_RECOGNIZED;
}

The callback function will provide a key (the name of the settings) that is a string type, and a golioth_settings_value that includes the value, as well as an indicate of the value type (bool, float, string, or int64). The callback function should validate that the expected key was received, and test that the received value is the proper type and within your expected bounds before acting upon the data.

The final piece of the device settings puzzle is to return an enum value indicating the device status after receiving a new setting. This is used by the Golioth Cloud to indicate sync status. Our example demonstrates the GOLIOTH_SETTINGS_SUCCESS and GOLIOTH_SETTINGS_KEY_NOT_RECOGNIZED status values, but it’s worth checking out the doxygen reference for golioth_settings_status to see how different invalid key and value messages can be sent to Golioth for display in the web console.

Coordinating with the Golioth Cloud

The device settings key format is tightly specified by Golioth, allowing only “A-Z (upper case), 0-9 and underscore (_) characters”. We recommend that you add a key to the Golioth web console while writing your firmware to ensure the device knows what to expect.

Each device page includes a status indicator to show if the settings are in sync with the Golioth cloud.

Additional information is available when a device is out of sync. Here you can see that hovering over the information icon indicates the key is not valid. For this example I created a VERY_IMPORTANT_BOOL_7 but didn’t add support for that to the firmware. This is the result of our callback function returning GOLIOTH_SETTINGS_KEY_NOT_RECOGNIZED. In cases like this, Golioth’s Over-the-Air firmwmare update (OTA) service can help you to push a new firmware to your devices in the field that will recognize the newly created Settings variable.

IoT Fleet control on day one

The pain of IoT often comes when you need to scale. Golioth’s mission is to make sure you avoid that pain and are ready to grow starting from day one.

Our device settings service gives you the power to remotely change settings on your entire fleet, on a group of devices, and all the way down to a single device. You are able to verify your devices are in sync, and receive helpful information when they are not. Take Golioth for a test drive today, our dev tier is free for the first 50 devices.

Today we’re announcing a new feature on the Golioth Console and on our Device SDKs that enables Remote Procedure Calls (RPCs) for all users on the platform. From the cloud, you can initiate a function on your constrained device in the field, ensure the device received and executed the command, and receive a response from the device back to the Cloud.

What is a Remote Procedure Call (RPC)?

A Remote Procedure Call allows you to call a function on a remote computing device and optionally receive a result. An easy way to think about it is you’re calling a function, like you would in any other program…you’re just doing it from another computer. In this case, you’re triggering actions from the Golioth Cloud.

RPC from the Golioth Cloud (Console)

Each device in your project has a page where you can view details about things like LightDB State, LightDB Stream, Settings, and now RPC. Our Console includes an interface to directly send RPCs to the remote device. The URL will look something like:

https://console.golioth.io/devices/<YOUR_DEVICE_ID>/management/rpc

In all of our examples, we are sending an RPC to single devices. However, they can also be triggered from the REST API. As a reminder, any function you see on the Golioth Console is available on the REST API.

One critical function of RPCs is a confirmation that the remote function has actually run. The device firmware needs to send back a success message that the function has completed, and optionally a returned value. When there is a problem connecting with your device and the RPC does not complete successfully, you will see a screen that looks like this:

An RPC sent to a device that was disconnected from Wi-Fi

Also note that round trip time is measured for all RPCs, including successful ones. Transit times will depend upon your connectivity medium, in addition to the processing time of the function on the remote device.

When an RPC successfully completes, you can click the button with 3 dots to receive the returned value. In the example and in the video, we were using a method called double that takes an integer input, multiplies it by two, and then returns the value to the Cloud. Below, you can see the result when we sent “double” method with a parameter of “37”.

RPC from the Device SDK perspective

Any new feature on Golioth has Device SDK support, in addition to the new APIs and UIs on our Web Console. Earlier this week, Nick wrote about how we test hardware and firmware at Golioth, especially when a new feature is released across the platform. Now that we support 3 SDKs (Zephyr, NCS, ESP-IDF), the testing area has increased.

In the video, the focus is on ESP-IDF, which has a simple way to set up and respond to new RPCs. First, we register the new method, so we’ll recognize the command coming from the Golioth Cloud:

The function that we tie to that newly registered RPC needs to return the RPC_OK variable for the Cloud to be alerted that the function has processed properly.

If you have satisfied these requirements in the ESP-IDF SDK and copied the format, you can customize logic to do whatever task you’d like on the remote device. Let’s look at some examples.

Use cases for an RPC

The double() example is a simple showcase of the minimum requirements to create an RPC in the ESP-IDF SDK. We send a command and a value, we return a modified value.

The remote_reset command we created and showcased in the video is more like a critical function you would want to add to your project. When you want to trigger a remote function like a reset, you want to ensure that the command was properly received, that the function executed, and then that there was output data that validated the reset has happened. In the final point, that includes inferring that the device has restarted from the log messages also being sent back to the Golioth Console. Put all together, it’s a reliable way to tell the device has been reset.

Other use cases could be as simple as sending arbitrary text to a display. You would still want to know the text has been received and properly sent to the physical display. Or perhaps you have a valve and you want to be able to send an arbitrary value to the valve, but you also want to take a reading on an encoder that measures the distance the valve has moved.

Many of these functions could also be achieved with LightDB State (which the RPC service is built upon), but the context for creating an RPC is more targeted at situations like the examples above.

What will you build?

RPCs are another way for you to communicate with your constrained IoT devices from the Golioth Cloud and to get useful information back from your devices. You can start testing out this feature today.

For more questions or assistance, check out our Forums, our Discord, or drop us a note at [email protected].



Golioth just rolled out a new settings service that lets you control your growing fleet of IoT devices. You can specify settings for your entire fleet, and override those global settings by individual device or for multiple devices that share the same blueprint.

Every IoT project needs some type of settings feature, from adjusting log levels and configuring the delay between sensor readings, to adjusting how frequently a cellular connection is used in order to conserve power. With the new settings service, the work is already done for you. A single settings change on the Golioth web console is applied to all devices listening for changes!

As you grow from dozens of devices to hundreds (and beyond), the Golioth settings service makes sure you can change device settings and confirm that those changes were received.

Demonstrating the settings service

Golioth settings service

The settings service is ready for you use right now. We have code samples for the Golioth Zephyr SDK and the Golioth ESP-IDF SDK. Let’s take it for a spin using the Zephyr samples.

I’ve compiled and flashed the Golioth Settings sample for an ESP32 device. It observes a LOOP_DELAY_S endpoint and uses that value to decide how long to wait before sending another “Hello” log message.

Project-wide settings

On the Golioth web console, I use the Device Settings option on the left sidebar to create the key/value pair for this setting. This is available to all devices in the project with firmware that is set up to observe the LOOP_DELAY_S settings endpoint.

Golioth device settings dialog

When viewing device logs, we can see the setting is observed as soon as the device connects to Golioth. The result is that the Hello messages are now issued ten seconds apart.

[00:00:19.930,000] <inf> golioth_system: Client connected!
[00:00:20.340,000] <inf> golioth: Payload
                                  a2 67 76 65 72 73 69 6f  6e 1a 62 e9 99 c4 68 73 |.gversio n.b...hs
                                  65 74 74 69 6e 67 73 a1  6c 4c 4f 4f 50 5f 44 45 |ettings. lLOOP_DE
                                  4c 41 59 5f 53 fb 40 24  00 00 00 00 00 00       |[email protected]$ ......
[00:00:20.341,000] <dbg> golioth_hello: on_setting: Received setting: key = LOOP_DELAY_S, type = 2
[00:00:20.341,000] <inf> golioth_hello: Set loop delay to 10 seconds
[00:00:20.390,000] <inf> golioth_hello: Sending hello! 2
[00:00:30.391,000] <inf> golioth_hello: Sending hello! 3
[00:00:40.393,000] <inf> golioth_hello: Sending hello! 4

Settings by device or by blueprint

Of course, you don’t always want to have the same settings for all devices. Consider debugging a single device. It doesn’t make much sense to turn up the logging level or frequency of sensor reads for all devices. So with Golioth it’s easy to change the setting on just a single device.

settings change for a single device on the Golioth console

In the device view of the Golioth web console there is a settings tab. Here you can see the key, the value, and the level of the value. I have already changed the device-specific value in this screen so the level is being reported as “Device”.

[00:07:30.466,000] <inf> golioth_hello: Sending hello! 45
[00:07:40.468,000] <inf> golioth_hello: Sending hello! 46
[00:07:43.728,000] <inf> golioth: Payload
                                  a2 67 76 65 72 73 69 6f  6e 1a 62 e9 9c 17 68 73 |.gversio n.b...hs
                                  65 74 74 69 6e 67 73 a1  6c 4c 4f 4f 50 5f 44 45 |ettings. lLOOP_DE
                                  4c 41 59 5f 53 fb 40 00  00 00 00 00 00 00       |[email protected] ......
[00:07:43.729,000] <dbg> golioth_hello: on_setting: Received setting: key = LOOP_DELAY_S, type = 2
[00:07:43.729,000] <inf> golioth_hello: Set loop delay to 2 seconds
[00:07:50.469,000] <inf> golioth_hello: Sending hello! 47
[00:07:52.471,000] <inf> golioth_hello: Sending hello! 48

When I made the change. the device was immediately notified and you can see from the timestamps that it began logging at a two-second cadence as expected.

Golioth settings applied at the blueprint level

It is also possible to change settings for a group of devices that share a common blueprint. Here you will find this setting by selecting Blueprint from the left sidebar and choosing your desired blueprint.

Settings are applied based on specificity. The device-level is the most specific and will be applied first, followed by blueprint-level, and finally project-level. Blueprints may be created and applied at any time, so if you later realize you need a more specific group you can change the blueprint for those devices.

Implementation: The two parts that make up the settings service

Fundamentally, there are two parts that make our device settings system work: the Golioth cloud services running on our servers and your firmware that is running on the devices. The Golioth device SDKs allow you to register a callback function that receives settings values each time a change is made to the settings on the cloud. You choose how the device should react to these settings, like updating a delay value, enabling/disabling features, changing log output levels, really anything you want to do.

Don’t worry if you already have devices in the field. You can add the settings service or make changes to how your device handles those settings, then use the Golioth OTA firmware update system to push out the new behavior.

Take control of your fleet

Scale is the hope for most IoT companies, but it’s also where the pain of IoT happens. You need to know you can control your devices, securely communicate with them, and perform updates as necessary. Golioth has you covered in all of these areas. The new settings service ensures that your ability to change how your fleet is performing doesn’t become outpaced by your growth.

This article is an introduction to the concept of “The Five Clouds of IoT.” It’s a tool I’ve been developing for some time as a way to help people trying to understand the role of the cloud. This is a mental model I developed as a way to explain service offerings to people interested in building fleets of IoT devices. It includes services developed in-house and services they choose to purchase from external providers.

Today I will discuss the genesis of these classifications and why there is more than one cloud type in the first place. In future articles, I’ll take a deep dive into each of these clouds to compare and contrast their features and look at example services.

I believe it’s important for us to focus our understanding of these broadly-general terms (like cloud and IoT). Doing so lets us define what problems need to be solved in the IoT space, and how best to approach them.

Giving advice about IoT Cloud Services

I have been building internet connected (IoT) devices for a long time. When someone comes to me for advice on their startup or business enhancement, they typically ask for guidance on selecting from different service offerings in the marketplace. There have been, and continue to be, many options out there.

The conversation usually starts out with, “should I use foo for software updates? Or is bar better because it includes more stuff?” They’re coming from the perspective of looking for solutions without understanding the problems they need to solve in the first place.

So as a first step I ask questions about their needs. Questions like:

  • How are you connecting to the internet?
  • What kind of device are you building on?
  • What’s the scale of your deployment?
  • What’s your cost and cost structure?
  • What is your business model?

But the most important questions to answer for picking cloud services are:

  • What are you willing to outsource?
  • What should you outsource?
  • What would get you to market faster if you went with a provider?

From there we can have a more grounded conversation on which aspects of the cloud are needed and which combination of providers they might want to evaluate. Very few service offerings will cover every aspect of an IoT deployment and business needs.

The more of these conversation I’ve had, the more I started to realize that there might be different types of IoT cloud solutions. In fact, I think there are five. And while in practice different cloud companies might offer overlapping features, describing them as separate clouds will help us better understand the core strength of each cloud type and why we might want to use them.

Why are there “Five Clouds of IoT”?

Here are The Five Clouds of IoT, as I define them:

  • The device cloud
  • The connectivity cloud
  • The data cloud
  • The application cloud
  • The development cloud

“You’re just making these up!”, you say? Yes and no. These are classifications based on the service offerings of companies throughout the ecosystem, including the company I founded a couple of years ago (Golioth).  But at the end of the day, these are my classifications and how I view the IoT ecosystem…so yeah, I’m making these up.

However, each cloud represents a business case being served. Each cloud type I listed has a prime example of at least one company serving a particular area of focus. That’s how big the market is and how much need exists for services.

Bringing IoT to the Masses

Each IoT cloud solution helps make deployments possible without massive internal cloud teams at a device maker or service company in the IoT space. Someone who wants to keep their core team small can do so by hiring out parts of the business to different service companies representing one or more of the Five Clouds. They focus on a particular part of the business and lean on service providers to help scale their application.

We’ve already mentioned Golioth as one example of a device cloud. We’re a device cloud because we focus on the management & security of devices and the data they produce. An example of a different cloud would be Soracom, which is a connectivity cloud that addresses different aspects of connecting devices to the internet that spans SIMs, data plans, VPNs, and more.

The key here is that the fundamental focus of a cloud like Golioth and Soracom are different:  device offerings vs connectivity offerings. You need to understand what problem you want to solve when choosing between clouds. For example, why you’d want to leverage Golioth, Soracom, or both.

Which Cloud is right for you?

In future articles in this series, I’ll take a deep dive into each individual cloud and look at example companies that exemplify the characteristics of each cloud. As you start to put together your business needs for your company or your next startup idea, you will be able to piece together which clouds you will need, and find some good companies that can help you achieve your goals.

Node-RED is a graphical programming tool that makes it easy to interact with web-based events. It’s called a “Low-code” solution because you can do a lot without writing much code. I love it because it’s the right balance of handling the hard stuff for me. Initial ease of use, while still making it possible to drop in custom code when I need it. I’ve been using that to control my IoT devices on the Golioth Cloud, and today I’m sharing how I do it.

Note: the concept of a node will be highlighted with bold text throughout this article to help clarify we’re discussing one of the blobs shown on screen in Node-RED

Why use Node-RED with Golioth

Earlier this year Ben Mawbey showed us how he uses Node-RED to manipulate data as it arrives on the Golioth cloud. This approach listens for realtime data using WebSockets. But this has a couple of limitations:

  • We will only see the data when it changes
  • We aren’t able to send or update data using WebSockets.

On that second point, the Golioth REST API lets us send/update data and query stored data.

Node-RED is a good choice here, since it’s relatively easy to set up a connection to WebSockets and the REST API. It’s powerful enough to do any data manipulation we want. It does need to run on a server, but on the upside that means it is always running and can be accessible to multiple end users via any web browser, no need to install an app. Let’s dive in!

Prerequisites

This example assumes you have already taken care of the following:

  • a Node-RED server
    • The Get Started page offers several solutions like running it locally on a Raspberry Pi, or on a cloud server
  • Golioth account, and a device added on the Golioth Console
    • As always, our getting started guide will walk you through all of these details
    • You can follow the demo below without having a hardware device, we just need to create a device on the Golioth Console to send data back and forth to the cloud

Connect Node-RED to WebSockets

The secret sauce in connecting a WebSocket is the URL which includes the Golioth API key. Go to the Golioth Console and choose API Keys from the left sidebar to create a new key:

The exact formatting of the WebSockets URL is detailed on our reference page, but I’ll show you how to do it here. Notice the three pieces of important data in the diagram below: project id, device id, and finally the API key.

I have chosen to connect to the dataendpoint to monitor LightDB state data. (If you want to monitor LightDB stream you can change data to stream.)

wss://api.golioth.io/v1/ws/projects/node-red-demo/devices/62695497404e12cd12628117/data?x-api-key=ynhJQQjLautKYLxQESuqB8VJLWMEVpH7

Setting up the Node-RED flow begins by adding a WebSocket-in node and connecting it to a debug node. I have also connected a JSON node for convenient data access later.

The WebSocket-in node is configured as follows:

The WebSocket type is “Connect to” which allows us to add a new URL. Click the pencil icon or the right side of that field and in the new window paste the URL. Because we are passing the API key as part of the URL, we do not need to add a TLS configuration.

Data will only appear on this WebSocket-in node when it first arrives on the Golioth Cloud. So generate an update by going to the Golioth Console and adding the key/value pairs shown above. In the Node-RED shown in the flow setup step, notice the debug output includes the raw payload as well as the JSON object.

Connect Node-RED to REST API

Setting up the REST API connection requires a bit of code, but uses the same project, device, and API key info from the last step. Two inject nodes (that send a 1 or a 0), a function node, an https request node, and a debug node complete this flow:

The inject node and http request node need a quick settings adjustment:

Set the payload of the inject node to pass 0 or 1 as a number (not a string). In the http request node, change the method to “set by msg.method”. The magic will all happen in the function node:

Code for this function is listed below. The variables at the top are used to set up the API URL, so you will need to enter your project id, device id, API key, and the LightDB state key that makes up the endpoint (led0 in my example).

var proj_id = "node-red-demo"
var dev_id = "62695497404e12cd12628117";
var api_key = "ynhJQQjLautKYLxQESuqB8VJLWMEVpH7";
var endpoint_name = "led0";

var dev_url = "https://api.golioth.io/v1/projects/" + proj_id + "/devices/";
var endpoint = "/data/" + endpoint_name;

var data = msg.payload;

var msg = {
	"method" : "PUT",
	"url" : dev_url + dev_id + endpoint,
	"headers" : {
		"Content-Type": "application/json",
		"x-api-key": api_key
	},
	"payload" : JSON.stringify(data)
};

return msg;

This code intercepts the incoming data (which will be a 0 or 1 from the inject node), formats it as a PUT command, and sends it to the http request node which will submit it to Golioth. In this demo, clicking one of the inject nodes updates the led0 value in LightDB state.

Head over to the Golioth Console and look at the LightDB state data for your device to see the changes. In practice, you can implement the desired state versus actual state principles discussed in my recent article and use this flow to update an LED on an actual piece of hardware.

Further Exercises: Dashboard/Web App

I’ve covered a lot of ground in this article and unfortunately have run out of column inches. But before signing off, I want to mention the potential for turning Node-RED flows into web apps.

The Node-RED dashboard node adds a UI which can be loaded on any browser. It looks spectacular with almost no work from us. Here you can see I’ve set up a display that shows the state of the LED, displays the latest value of the counter, and adds two buttons to turn the LED on or off.

If you want to test this out, here is an export of this flow that you can import into your Node-RED.

A word of caution: your flow contains an API key for accessing device information on Golioth. This must be kept secure. Please make time to review how to secure Node-RED and ensure that you authenticate users if you decide to build and share a web interface.

Communicating with IoT devices over a network connection presents a few challenges you must consider when designing your firmware. The most obvious is how to deal with spotty connections. Did your device get the command you sent? Does the reported state in the cloud accurately reflect the actual device state?

At Golioth we’ve built a device cloud that eases the process of provisioning, connecting with, and controlling fleets of IoT devices. To get the most out of the platform consider using a few design patterns related to Digital Twin, a virtual representation of a device that is present in the cloud and provides a framework for interacting with the real hardware.

I’ll demonstrate this using the Golioth platform, but of course the concept is applicable to all connected devices.

Avoiding Confused Users and Confused Devices

While there are innumerable ways in the IoT realm to confuse your users and your devices (trust me, I’m trying to find them all), the most obvious is the challenge keeping the device and the cloud in sync with each other. For ease of understanding, let’s consider a box with one button and one LED that is connected to the internet over a cellular connection. We want the button to toggle the LED but also allow the cloud side to change the state of the LED. This might represent the state of some running service, but to keep it simple we’ll leave that out of the example.

If we rely on the cloud to control the device LED, the user will push the button and have to wait for the button press to make it to the cloud, wait for the state of LED on the cloud to be changed, and wait for this change to make its way back to the device to update the LED. The user is likely to think the button press was missed and press it again.

If the device directly controls the LED, what happens if the cloud misses the button press because of connectivity issues? When not carefully planned for, the state of the LED will be different from the state of the service in the cloud. What happens if the LED state on the cloud is changed at almost the same time the button is pressed? We have a race condition to see which update propagates the fastest.

One design pattern we should all be familiar with uses a separation of state from command/control so that the device and its digital twin will remain in sync even when there are latency or connection issues. A device just coming on line should be able to quickly enter a desired state from the server, and report back the actual state.

Keeping Desired State and Actual State Separate

The issues outline above can be avoided by using different endpoints for a device to communicate with its virtual equivalent.

  • On the cloud there will be one representation where the physical device reports its current state. For the cloud this data is read-only, only the device can make updates to it.
  • A separate representation is made for the desired state of the device. The cloud side can make changes to this and the physical device will watch for and react to these changes. The physical device usually has a mechanism that indicates the desired operations were received.

Digital twin uses both a desired state and an actual stateOur simple example only has one “actual state” variable that keeps track of the LED state. A server might watch this data via a WebSocket to toggle some service as the value changes.

The cloud can populate the “desired state” with endpoints that request changes to the LED status. This might happen when some service the cloud is watching changes state and the IoT device needs to be aware of that.

Demo Using Golioth

Golioth stores persistent data using LightDB state. We can use a simple data structure to represent the digital twin of our hypothetical IoT device:

{
  "state": {
    "led": 0
  },
  "cmd": {
    "led_on": 1649691282
  }
}

The state endpoint stores the last-reported state (on) of the device’s LED. The cmd endpoint reflects the cloud’s desire for that LED to be on by setting the led_on key to the current timestamp. The cloud could also set led_off to a timestamp, and when the device acts upon the desired state, it can compare timestamps for all existing keys to establish which command is the most recent.

I like to have the IoT device delete the command keys once they are received (another approach would be to have the device set an acknowledged value to the timestamp the desired state was serviced). In the above example, since the led_on key exists, we assume the device has not yet seen it. Once it does, the device will turn on the LED, update the status key for that LED to 1, and delete the cmd/led_on endpoint.

Our app can be set up to watch the desired state by observing the cmd endpoint and running an on_update function when a change is detected.

err = golioth_lightdb_observe(client,
					GOLIOTH_LIGHTDB_PATH("cmd"),
					COAP_CONTENT_FORMAT_TEXT_PLAIN,
					observe_reply, on_update);

The IoT device will write a simple string of “0” or “1” as the actual state when the button is pressed, and each time the device acts upon a desired state request.

char sbuf[2] = "0";
if (led_state &amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp;amp; 0x01) {
	sbuf[0] = '1';
}
int err = golioth_lightdb_set(client,
					GOLIOTH_LIGHTDB_PATH("state/led"),
					COAP_CONTENT_FORMAT_TEXT_PLAIN,
					sbuf, strlen(sbuf));

So let’s imagine that our IoT device is in power-saving mode. When it wakes up and connects to the network, it will immediately see the command endpoint is requesting an LED state change. Using this design pattern means your desired state changes are not missed; even when a network connection is unavailable the device will be able to update to the most recent commands the next time it connects.

You can try this out for yourself on the Golioth cloud right now. I’ve implemented the desired state pattern in sample code, and the Dev tier of Golioth lets you test 50 devices on our platform for free.

Further Learning

At its core, this design pattern is incredibly simple. When you put it into use, things may become more complex. Perhaps you want to have a command queue so that there is a history of changes for the device to review the next time it connects to a network. Instead of deleting the commands when acting upon them, a device may place an acknowledged timestamp next to them, or some other scheme that fits your needs. But at its core, the separation between a device reporting it’s state and the cloud requesting state changes is an excellent IoT approach, and a great way to start learning about the concept of digital twins.

Visualizing Golioth IoT Data on Grafana Cloud

Live data visualization shows you what is going on with your IoT fleet right now, and it makes for impressive customer demos. We previously wrote about how to visualize live data on the self-hosted version of Grafana using the WebSocket plugin we wrote. Today let’s walk through how to connect live Golioth IoT data to Grafana Cloud.

Overview

Golioth is the translation layer between your fleet of IoT devices and the cloud. Among our many ways of accessing the collected data, WebSockets are one way to get live updates as soon as the data arrives.

Grafana visualizing temperature, pressure, and humidity

We wrote a WebSockets plugin for Grafana, the monitoring and observability software. The plugin is open source (here’s the code repository) and as of just a few days ago it’s available in Grafana Cloud, the cloud-hosted version of the software. Today I’ll guide you through:

  1. Sending some temperature sensor data to Golioth
  2. Configuring the Golioth WebSocket API on the Grafana Cloud
  3. Graphing the temperature data in realtime

This example has everything you need to adapt it for your own needs.

1. Send Sensor Data to Golioth

Prerequisite: You should already have a Golioth account, and have the Zephyr toolchain installed. To do so, please follow the Golioth Getting Started guide and Setting Up Zephyr for ESP32.

For this guide I’m using the LightDB Stream example that is part of the Golioth SDK, and running it on an ESP32. This example is a good one, since it will either use a temperature sensor you have configured in the devicetree, or simulate a temperature sensor if there is not one available.

Get device credentials from console.golioth.io

First, find your device credentials in the Golioth Console by selecting Devices from the left sidebar menu and clicking the name of your device on the resulting list.

CONFIG_GOLIOTH_SYSTEM_CLIENT_PSK_ID="[email protected]"
CONFIG_GOLIOTH_SYSTEM_CLIENT_PSK="a_strong_password"

CONFIG_ESP32_WIFI_SSID="your_wifi_ssid"
CONFIG_ESP32_WIFI_PASSWORD="your_wifi_password"

Now add the device credentials–Identity (PDK-ID) and Pre-Shared Key (PSK)–and your WiFi access point credentials to the project’s prj.conf file. This file should be located at ~/zephyrproject/modules/lib/golioth/samples/lightdb_stream/prj.conf. Add the lines in the format shown above.

$ west build -b esp32 samples/lightdb_stream -p
$ west flash

Finally, use the commands above to build and flash the sample to your ESP32.

streaming temperature data in Golioth console

If you go to Monitor→LightDB Stream you will see new temperature data coming in every five seconds. In this window, choose the Last 4h setting from the time selector, your device from the device selector, and enable 5s auto-refresh in the upper right.

Each time one of these packets comes in, the data will be automatically updated in Grafana. We just need to set that up, which is next!

2. Configure the Golioth WebSocket API in Grafana Cloud

generating Golioth API keys

The prerequisite for this step is to get an API key from Golioth.

  1. Use the API Keys option on the left sidebar of the Golioth Console
  2. Click the Create button in the upper right of the main window
  3. In the resulting dialog (show above), press the Create button

The final dialog displays the key and some useful path information. We will use this path along with the wss://api.golioth.io/v1/ws/ WebSocket endpoint which I looked up in the Golioth WebSocket docs.

Grafana Cloud login

Log into Grafana Cloud. There are a number of services offered, the one we want is simply called Grafana.

On the left sidebar, hover over the gear icon and select Plugins. Search for WebSocket on the next screen and click the “WebSocket API” tile. Follow this 3-step process to add the WebSocket plugin (shown in the screenshots above):

  1. Click the Install via grafana.com button
  2. On the next screen click the Install plugin button
  3. Go back to the previous screen and refresh that page. It may take a minute or two, but when the new button appears click Create a WebSocket API data source

Grafana WebSocket data source configuration

This brings us to setting up our data source.

  1. Name can be anything you want
  2. Host is the wss://api.golioth.io/v1/ws/ from the Golioth Docs
  3. Click the Add header button
    1. Enter x-api-key for the header value
    2. Paste your API key from the Golioth Console in the Value box
  4. Click the Save & test button

We have completed the WebSocket connect between Grafana and Golioth. Now it’s time to visualize the incoming data!

3. Graphing Temperature Data in Grafana

In the left sidebar of Grafana, click the big plus icon and choose Dashboard, then click Add Panel.

Grafana panel setup

  1. In the Data source box on the left, select the name of the data source you just set up.
  2. For now, enter just a $into the Field box
  3. Click the Path tab
    1. Follow this format which was shown on the confirmation dialog when you created your API key:/projects/<name of Golioth project>/stream
    2. Notice I have switched from /devices to /stream.
  4. At the top of the window in the center, turn the Table view on

You should begin to see JSON data come in over the table view. Remember that WebSockets visualize realtime data, so JSON will only appear when new packets are sent.

Now that we’ve seen the JSON data coming in, we can use it to identify two types of data to use for the graph: temperature and timestamp.

More specific JSON fields

Going back to the Fields tab, we can change the $ character (which means to show all the JSON coming in) to a specific key/value pair.

  • Enter $.result.data.timestamp
    • You will see the data in the table-view change as you type, this is helpful in navigating the hierarchy
  • Click the + button all the way to the right of the Field box to add another field
  • Enter $.result.data.data.temp

Graphing simulated temperature data

When you click the Table view button at the top, the view will be replaced by a visualization of your data. Here you can see it is obvious that I’m using simulated temperature data. You can also change the way it is visualized by clicking on the Time series menu in the upper right.

Conclusion

This is one simple example that is graphing a single stream from one device. But the principle scales with your IoT fleet. Graphing large numbers of devices across multiple projects takes little more than changing how you use your Path and Field settings on the panel. With Grafana you can easily group together multiple panels into a dashboard, with visualization options tailored to almost any data type.



Golioth has just released a Grafana WebSocket Data Source plugin. This open source plugin allows you to create a graphic dashboard using data from any WebSocket URL that uses JSON formatting. This means you can you directly connect the Golioth Cloud API and have Grafana render incoming data in real time as graphs, charts, maps, etc.

Grafana Takes Care of Data Visualization

Temperature data display as graphs

Realtime data from Golioth devices looks great in Grafana!

Grafana is an open source visualization and analytics software from GrafanaLabs. It allows you to query, visualize, alert on, and understand your metrics no matter where they are stored. We chose Grafana because we heard it mentioned multiples times by our community members and found that it streamlines the process of managing device data and visualizing. You can build from source and run it locally (the power of open source), or use the free tier of the hosted Grafana Cloud platform.

We’re Going to Need WebSockets

At Golioth, we recently added WebSocket support for some of our services like Logs, LightDB State, and LightdDB Stream. Actaully, Chris wrote a blog post all about it. You can now connect to a WebSocket URL and get real-time data updates from your devices without the need to poll for updates like you would with a REST API.

As awesome as it is, Grafana didn’t have a WebSockets plugin, so we created one! It allows you to connect to any WebSocket URL and visualize the data in Grafana. You can get a copy of the WebSockets plugin code in our repo. But we have also submitted it as an official plugin – it should be available in Grafana soon!

Let’s Try the Demo!

Setting Up a Device to Send Data

As a hardware beginner, I followed one of our easiest samples using PlatformIO and our Arduino SDK to get my ESP32 board connected to our platform, see our examples folder on our Arduino SDK repo. I’m writing data on both of our services in a 5 seconds loop, updating my device’s state with LightDB State and reporting time series data for our LightDB Stream service.

// Every 5 seconds loop
...
  int core_temp = randomNumber(40, 60);
  int room_temp = randomNumber(27, 33);
  int uptime = millis() / 1000;
  String payload =
    "{
      \"core\":
        {
          \"temp\":" + String(core_temp) + ",
          \"uptime\":" + String(uptime) +
        "},
    \"room\":
      {
        \"temp\":" + String(room_temp) + "
      }
    }";

  client->setLightDBStateAtPath("/", payload.c_str());
  client->sendLightDBStream("/", payload.c_str());
...

This small program sends random numbers as core/room temperatures, and the device’s uptime. We have data, now let’s graph it!

Golioth’s WebSockets API

LightDB state data

Devices > Your Device > LightDB State

LightDB Stream Data

Monitor > LightDB Stream

WebSockets “listens” for changes, so every 5 seconds those updates on State and Stream are also available thru Golioth’s WebSocket API. We can follow the WebSockets docs to setup a connection to listen to them.

Below you can see how the WebSocket hosts URLs are formatted. Use the Golioth Console to find the projectId, deviceId, API key, and any paths you need. (This information is also available using the goliothctl command line tool.)

LightDB State

// Websocket URL format: wss://api.golioth.io/v1/ws/projects/{projectId}/devices/{deviceId}/data{/path=**}?{x-api-key|jwt}={API_KEY|JWT}

wss://api.golioth.io/v1/ws/projects/smart-house/devices/61d315e441da400dd6934493/data?x-api-key={projectApiKey}

LightDB Stream

// Websocket URL format: wss://api.golioth.io/v1/ws/projects/{projectId}/stream?{x-api-key|jwt}={API_KEY|JWT}

wss://api.golioth.io/v1/ws/projects/smart-house/stream?x-api-key={projectApiKey}

With those I was able to test the endpoint using websocat to make sure that the data my device was sending created notifications through the WebSocket connection as expected.

websocat command line tool used to test WebSocket feed

Grafana WebSocket Plugin Setup

For this demo I’m running everything locally (both Grafana and the Plugin itself), but we have submitted the signed plugin to Grafana’s Cloud so soon you will be able to find it there by default.

To use the plugin, there are a few configuration steps we need to follow:

  • Once you’ve logged into Grafana, go to the Configuration page (gear icon) and then to Plugins
  • Search for WebSocket API, select and then click on Create a WebSocket API data source

Now we fill in the fields as the API requires and hit save. For Golioth’s WebSocket API you can see I’ve entered the URL, and I’ve specified x-api-key and stored the API key that I generated on the Golioth Console.

Grafana WebSocket data source

Notice that I’m not using the full path, but only through the project level (smart-house). This way we can select the specific path we want to listen to later on the Panel’s Query page. This allows more flexibility.

Building the Dashboard that Shows the Data

With the data source set up, it’s time for us to build the query on an actual panel.

Something to keep in mind is that, right now, it will only listen to future events, so if there’s any update on the Query Field, Path, Panel or Dashboard, the current stored data will be wiped.

Graphing LightDB Stream:

  • Hover on the plus sign at the sidebar and select Dashboard
  • Then click on Add a new panel
  • Select WebSocket API under the Query’s data source
  • Go to Query A Path tab and fill with your desired path. In my case /stream

Grafana WebSockets path setting

  • Under Fields tab, use JSONPath reference to transform the JSON result into something that the dashboard can display. Here I’ve used $.result.data.timestamp, $..core.temp, and $..room.temp
  • I want to display the last 5 minute events of my device’s temperature, both for the core and room. So I changed the panel’s type into Time Series on the top right corner, and filled with the fields required:
  • Hit Save, and its done.

Grafana WebSockets field configuration

As long as data is streaming in from a device, it will be graphed in real time. One tip as you get used to handling data, try starting with Table View on to better understand the JSON by your query.

Displaying LightDB State

To create another panel for the LightDB State we can just duplicate the first one and update his its Path, so:

Grafana state data path configuration

There’s a small differences here, LightDB State can have deeper paths e.g. .../data/core/temp but they will only be notified via WebSockets when there’s an update on them. Because I want to listen to multiple path updates for this Panel, I will leave the path set to the root level, that is .../data.

Grafana state field queries

  • Transform the query fields to use $..core.temp and $..room.temp
  • Hit Save, and it’s another one done.

Final Results

Grafana state field queries

Like that, we have 2 panels ready to listen for updates coming from both LightDB Stream and State in real-time. Feel free to add more data and to listen to different State paths.

Conclusion

Grafana is an awesome tool that allows us to connect and create professional visualizations. Because it is open source, a major part of its improvement over time is a result of its community. We’re building an amazing platform at Golioth and we also want to empower our community with the freedom to build things they love with us. With WebSockets now available on our platform, we built this plugin to share that excitement with our users and with the entire world.

Hopefully you’ll give this a try, and we want your feedback! Get in touch with us on the Golioth Discord server and please join us there for our Office Hours every Wednesday at 10 am Pacific Time.
